AUDIO AND VIDEO DOOR ENTRY SYSTEM - CODED PANEL WITH DISPLAY
PROGRAMMING THE TELEPHONES
Programming T-540 Plus telephones:
If it is a general entrance door panel in a residential complex, only programme the monitors from their inner door panels, as
indicated in the instruction manuals supplied.
If it is an inner door panel in a residential complex or a door panel for a single building, programme the monitors as shown
below.
CONFIGURATION
****
SW1
1 2
P3
1 0
M
ON
CN1 P1
SW1
P3
ON
P3
P2
S
ON
CN1 P1
P3
P2
SI
ON
CN1 P1
P3
P2
Each apartment must only have one master unit; if there are parallel units, whether monitors or telephones, they must be
configured as slaves.
Make a call to check that the telephone has been successfully programmed. Programme the other
telephones in the same way.
1 0
After programming, exit by pressing .
2
Open the telephone to be programmed (see p. 157). In the SW1 DIP switch,
1 2
P3
select the P2 button function mode (see p. 156) and then press the P3
programming button.
ON
To show that the system is ready for programming, the door panel and the
telephone handset will emit a number of tones (the LED on the telephone will
P3
light up), enabling audio communication to be established with the door panel.
ON
Enter the code of the monitor to be programmed and then press the bell button.
P3
At this moment, the door panel and the handset will emit a number of tones
(the LED on the telephone will blink slowly).
To programme the telephone as the
will go out). Close the telephone.
To programme the telephone as the
CN1 P1
SW1 LED will blink rapidly), and then press the hang up button (the LED will go out).
ON
P3
Close the telephone.
P2
To programme the telephone as the
button (the LED will blink rapidly), and then press the hang up button (the LED
CN1 P1
SW1
ON
P3
will go out).
P2
Close the telephone.
To enter configuration mode, press the key button
three times and then enter the secret
7 1 8
administrator pin (factory code 2718) as
described on p. 129.
Master
Slave
, press the hang up button (the LED
, press the P1 lock release button (the
+ , press the P2 function
Slave Intercom
158
