AUDIO AND VIDEO DOOR ENTRY SYSTEM - CODED DOOR PANEL
PROGRAMMING THE TELEPHONES - GENERAL ENTRANCE DOOR PANEL ONLY
Programming T-540 Plus telephones from a general entrance door panel (SW1-1 ON):
To programme the telephone from a inner door panel, see p. 105.
SW1
1 2
P3
0 0 1 1 2 5
M
ON
CN1 P1
SW1
P3
ON
P3
P2
S
ON
CN1 P1
P3
P2
SI
ON
CN1 P1
P3
P2
Each apartment must only have one master unit; if there are parallel units, whether monitors or telephones, they must be
configured as slaves.
0 0 1 1 2 5
Note: The call code from a general entrance door panel consists of the column or building code + the code of the
apartment to be programmed:
Column : 1 - 254
Apartment:0 - 999
Locate the SW2 DIP switch on the general entrance door panel situated on the top left-hand
side of the back of the sound module. With switch 1 OFF and switch 3 ON, set switch 2 to
ON: the general entrance door panel will emit a tone indicating that it has entered
programming mode.
In systems with more than one door panel, only carry out this procedure on the main door
panel.
Open the telephone to be programmed (see p. 104). In the SW1 DIP switch,
1 2
P3
select the P2 button function mode (see p. 103) and then press the P3
programming button.
ON
To show that the system is ready for programming, the door panel and the
telephone handset will emit a number of tones (the LED on the telephone will
P3
light up), enabling audio communication to be established with the door panel.
ON
P3
To programme the telephone as the
will go out). Close the telephone.
To programme the telephone as the
CN1 P1
LED will blink rapidly), and then press the hang up button (the LED will go out).
SW1
ON
P3
Close the telephone.
P2
To programme the telephone as the
button (the LED will blink rapidly), and then press the hang up button (the LED
CN1 P1
SW1
ON
P3
will go out).
P2
Close the telephone.
Make a call to check that the telephone has been successfully programmed.
Programme the other telephones in the same way.
Once the programming has finished, set the programming switch to OFF. If this is not
done, the door panel will emit tones to indicate that the system is still in programming
mode.
Enter the code of the telephone to be programmed, followed by the
key button. At this moment, the door panel and the handset will
emit a number of tones (the LED on the telephone will blink
slowly).
Slave
, press the hang up button (the LED
Master
, press the P1 lock release button (the
+ , press the P2 function
Slave Intercom
