AUDIO AND VIDEO DOOR ENTRY SYSTEM WITH NEXA CODED PANEL
SYSTEM CHARACTERISTICS
- Microprocessed devices with simplified wiring (bus without call wires):
Audio door entry system with 4 common wires.
Video door entry system with 3 common wires plus coaxial cable
Video door entry system with 4 common wires plus twisted pair
- Can be combined with "Nexa Modular" and "Inox Modular" door panels
- Configuration programmable using a numeric keypad, PC or tablet. USB or wireless connection (module
CD-NEXA/BT required)
- 2 potential-free relay outputs (NO, C, NC), 1 lock release relay (CV1, CV2) and digital panic output (to alarm control
centre).
- Residents list with up to 1,990 contacts
- 4, 5 or 6 digit programmable codes
- Possibility of using the same user pin for the different relays and digital panic output
- Relays 1 and 2 with three potential-free contacts (NO, C, NC), configurable by programming in stable or impulse mode
(maximum load: 18Vac/1A 18VA or 24Vdc/0.75 A 18 W).
- Impulse mode activation time programmable from 1 to 99 seconds for each relay and digital panic output.
- Lock activation time programmable from 3 to 15 minutes.
- Wrong code lock programmable for 3 to 9 attempts and at an interval also programmable from 1 to 15 minutes
- Up to 3 inputs for relay 1 external activation button (PL1), relay 2 (PL2) and relay 3 (AP).
- OLED display (module N3403/AL or NX3403) and front LEDs to show operating status.
.
.
.
.
.
.
.
