- Page 1 BIOMASS BOILER ATTACK PELLET 30 AUTOMATIC PLUS INSTRUCTIONS FOR USE W W W . A T T A C K . S K...
-
Page 3: Important Information
WARRANTY FOR BOILER IS NOT VALID IF: it is not operated with prescribed fuel - pellets adequate to the approved fuel specification. there is no mixing device Regumat ATTACK-OVENTROP installed in the system to ensure temperature of the boiler return water over 65°C. - Page 4 Boiler regulation ..........................7 Technical parameters ........................... 7 Dimensions of boiler ATTACK PELLET 30 AUTOMATIC Plus ............. 8 Main parts of boiler ATTACK PELLET 30 AUTOMATIC Plus ............8 Assembly and installation of boiler ..................... 9 Boiler connection scheme ........................11 Burner connection scheme .........................
-
Page 5: Introduction
Introduction: Dear customer, thank you for your confidence, expressed by purchase of our product – the ATTACK PELLET 30 AUTOMATIC Plus boiler for pellet combustion.We wish it serves you well and for a long time. Proper attendance of the boiler is one of the conditions for reliable and correct operation. -
Page 6: Purpose Of Usage
Purpose of usage The ATTACK PELLET is a modern boiler for wood pellet combustion. By its technology it saves environment and offers comfort comparable with usage of gas boiler. Boiler is intended for heating of family houses, shops, industrial objects and other similar buildings. -
Page 7: Boiler Regulation
Boiler regulation The ATTACK PELLET 30 AUTOMATIC Plus boiler for pellet combustion is regulated by control panel placed on the upper covering. 1 – Main boiler switch – Plugs boiler into / off the power 2 – Burner mode switch – switches burner between stand-by and operating mode 3 –... -
Page 8: Dimensions Of Boiler Attack Pellet 30 Automatic Plus
Dimensions of boiler ATTACK PELLET 30 AUTOMATIC Plus Main parts of boiler ATTACK PELLET 30 AUTOMATIC Plus 1 – boiler body 7 – turbulators 2 – covering 8 – flue collector with flue exhaust 3 – detachable ash container 9 – flow connection 1“... -
Page 9: Assembly And Installation Of Boiler
0,5 m from the sides and rear part of boiler. Above the boiler, there should be free space of at least 1 m. This space is necessary for ordinary operation, maintenance and eventual boiler servicing. It is inadmissible to place the ATTACK PELLET 30 AUTOMATIC Plus boiler in dwelling premises (including corridors)! Air inlet For correct boiler operation, it is necessary to ensure sufficient air supply for combustion. - Page 10 Selection and way of connection of regulation and control elements Boiler is delivered with basic regulation and control equipment. Connection of these elements is given on connection scheme. It is recommended to extended boiler regulation for next regulation elements for more comfortable and economical operation. Every pump in the system must be controlled by individual thermostat to prevent boiler undercooling at the return water inlet (return connection) under 65°C.
-
Page 11: Boiler Connection Scheme
Boiler connection scheme... -
Page 12: Burner Connection Scheme
Burner connection scheme CONNECTION CABLE L1 L2 7 8 9 PE 15 16 12 13 EK027 F1 F2 EK025 1 – Basic electronics – Contact without potential 2 – Display electronics 3 – Electronics of cleaning COLOUR MARKING: 4 – Display –... -
Page 13: Flue Connection
Flue connection Flue connection must empty into chimney vent. If it is not possible to connect boiler to chimney vent directly, appropriate extension of flue should be as short as possible (not longer than 1 m), without additional heating area and it has to ascend in direction towards chimney. Extensions of flue connection must be mechanically firmly joined, tight against flue leakage and easily cleanable. -
Page 14: Boiler Protection Against Corrosion
Boiler protection against corrosion Suitable solution of this problem is usage of the mixing device Regumat Attack-Oventrop). This solution enables creation of separate boiler and heating circuit and prevention against boiler undercooling under 65°C. Thereby it comes to decrease of water steams condensation and acid and tar creation in boiler exchanger and combustion chamber. -
Page 15: Operation Prescriptions
Operation prescriptions Boiler preparation for operation Before starting the boiler, make sure, that the system is filled with water, deareated and there is no pressure decrease of the heating water. Check tightness and construction of flue exhaust. To ensure quality function, the boiler must be attended in conformity with instructions given in this manual. Only adult person can operate the boiler. - Page 16 Container has to be closed during the boiler operation. Ash removing The ATTACK PELLET 30 AUTOMATIC Plus boiler is equipped with device for automatic ash removing into the detachable box. It is necessary to check the box 2x per season and to empty it, if necessary.
-
Page 17: Maintenance Of Heating System With Boiler
Short-time boiler stop If you wish to stop the boiler for a short time, turn the burner switch off and let the fuel burn down in the burner. Do not turn off the main switch. Long-time boiler stop When stopping the boiler for a long time, firstly – turn the burner switch off and let the fuel in the burner burn down. -
Page 18: Recommended Schemes Of Connection
Recommended schemes of connection... -
Page 19: Technical Description Of Burner
Technical description of burner Burner operation is based on principle of pellets falling from pellet feeder through inlet hose and inlet pipe on the grate to be burned. Burner is equipped with electric ignition device, that automatically lights pellets fallen on the grate. Ignition begins, when thermostat gives instruction to burner. -
Page 20: Technical Data Of Burner
Technical data of burner Model PELH30Plus Fuel Wood pellets, 6–10 mm Mode 8–12 kW; 14–30 kW Output range 8–30 kW, by 2 kW For boilers with heating chambers up to 3 m² Weight 28,5 kg Main voltage Main current ~230 V 10 A fuse WARNING! Electrical installation must be done by certified electrotechnician. -
Page 21: Description Of Burner Function
Description of burner function ATTENTION! Burner works with boiler thermostat only, eventually extended with room thermostat. In both cases it has to be connected through protection against boiler overheating. Normal start-up When thermostat gives instruction to burner, ventilator is started and photocell controls flame. If there is no flame, then comes the instruction for test blow-through of burner. -
Page 22: Usage Of Pellet Burner
Usage of pellet burner Pellet burner needs air for combustion. Thereby, boiler room must have opening for air inlet of at least 200 cm Pellet burner must not be started before it is verified, that smoke can freely flow through boiler and chimney into atmosphere. -
Page 23: Messages On Display
Messages on display Stand-by mode Nothing operates in the burner, burner awaits start signal from PAUSE thermostat. Thermostat turns on. FC: 0 % Step 1 Test blowing Ventilator starts to work, and when photocell measures value lower TEST-BLOWING than 5%, program continues. FC: ? % Step 2 Heat-up fuel feed Heat-up fuel feed is supplied into burner and program awaits... -
Page 24: Menu Messages
Menu messages Burner in standby mode. PAUSE FC: 0 % Press ”M” button Here you can change burner output. Level 1 = 8–12 kW, Level 2 = EFFECT LEVEL 14–30 kW. ENTER EXIT Range and output Levels are adjustable in advanced menu. Press ”+”... -
Page 25: Production Settings
Production settings Before being delivered, burner should be set in the following way: Generally accessible menu: Menu Production settings Selection Adjustable Output level 1 = 8 kW 1, 2, 3 8–12 kW 2 = 10 kW 3 = 12 kW Pellet dosing 95 % 50–200 %... - Page 26 How to change production settings To change settings, select the required menu /parameters. Change actual values by pressing „+“ . O:...indicates actual value, N:...can be adjusted to new value. Values can be increased by „+“ button and decreased by „–“. Change is confirmed and saved by „S“ button. Not to save changes, press „ESC“...
-
Page 27: How To Install Pellet Feeder And Container
How to install pellet feeder and container Install pellet container and pellet feeder. There should be min. height difference of 400 mm between opening of feeder and burner inlet pipe. In horizontal direction, opening of feeder and inlet pipe should be in min. distance of 150 mm (i.e. not vertically aligned). Fill container with pellets and connect feeder into power socket (230 V~). -
Page 28: Emergency Shut Down
Emergency shut down ATTENTION! In emergency case can be burner turned off by the main boiler switch and disconnection of boiler power plug from electrical socket. Cleaning and maintenance Burner has to be cleaned after every consumption of 2.000 kg pellets. It is based on assumption, that boiler keeps adequate amount of ash and the quality pellets are used. -
Page 29: Troubleshooting
Troubleshooting Burner stopped. Check alarm indicated on display. If display is black and without text, check thermal protection of boiler. If there is no error, probably it was switched off by thermal fuse. To restart burner, disconnect it from electricity, remove the cover and press the small button between connections of thermal fuse. - Page 30 Faulty sensor of thermostat Exchange sensor. Faulty sensor of thermostat Exchange sensor. Faulty circuit board Exchange circuit board. Fan works, while burner is under the Exchange circuit board. pause mode. Fan does not work, when it should. Exchange fuse of fan (800 mA); check connection;...
-
Page 31: Decomposed View
Decomposed view... -
Page 32: Accessories
Accessories Name Code Pellet container, 450 l PEL9700 Pellet feeder, 1.5 m PED150A Pellet feeder, 2.5 m PED250 Advanced menu Following data/parameters are adjustable by qualified person only. All aspects of the advanced menu are available by pressing the „S“ button. Actual setting is permanently indicated in the left bottom corner by „O:“... - Page 33 Setting of test-blow time Testblow time represents period of ventilation of boiler and TESTBLOW TIME chimney, before the combustion starts (10–100 seconds). ENTER < > EXIT By boilers with difficulty to achieve own draught it is suitable to increase the testblow time. Production setting is 15 sec. Setting of transition phase: Here you can set the period from the first flame detection until the TRANS.PHASE...
- Page 34 Modulation: By adjusted temperature difference ∆T, boiler output automatically MODULATION. decreases under the set level before the required boiler temperature ENTER < > EXIT is achieved. Setting the photocell sensitivity: Here you can set photocell sensitivity, i.e. value of light (in %) that PHOTOSENS.
- Page 35 Time of feeder operation: Here you can see, how long did the pellet feeder work. You can use STOKERTIME it to calculate energy consumtpion, etc. ENTER < > EXIT Test: Serves by troubleshooting. Here you can control components – MENU/TEST manually or automatically.
-
Page 36: Instructions To Disposal Of Product After Expiration Of Its Lifetime
Disposal of packaging has to be ensured by a scrapyard, eventually by a disposal site controlled by appropriate municipal authority. Accessories The ATTACK PELLET 30 AUTOMATIC Plus boiler is delivered functionally tested. It is packed and placed on wooden pallet. Pellet feeder is packed separately. Delivery includes the following accessories:... -
Page 37: Notes
Notes... - Page 38 Boiler commissioning certificate Data of the customer: (legibly) Serial number: ..........Name and surname: Date of commission: ......................... Service organization: Street: ..............ZIP code, town: ......................... Stamp, signature Tel.: ..............Obligatory service inspection after the 1st year of operation Date: ......
- Page 40 • ATTACK, s.r.o. producer reserves the right to change technical parameters and dimensions of boilers without previous warning. • Der Hersteller ATTACK, s.r.o. behält sich das Recht der technischen Veräderungen an Produkten ohne eine vorige Warnung. • Изготовитель ATTACK, s.r.o. оставляет за собой...
