Summary of Contents for ATTACK FD20
- Page 1 EN 06/2019 FD SOLID FIRE Instructions for use www.attack.sk...
-
Page 3: Table Of Contents
SUPPLY AND PACKAGING ..........................10 APPLIANCE FOR EXCESSIVE HEAT REMOVAL – COOLING CIRCUIT ..........11 9 BOILER ATTACK FD SOLID FIRE USED IN SYSTEM OF OPEN AIR EXHAUSTION AND NATURAL WATER FLOW ................................. 11 DIMENSIONS OF COOLING CIRCUIT ....................12 10 BOILER ASSEMBLY ............................ -
Page 4: Introduction
INTRODUCTION Dear customer, Thank you for your trust and purchase of universal boiler ATTACK FD SOLID FIRE . Boiler ATTACK FD SOLID FIRE is certified for burning wood and black coal. For right operation of your new product read at first instruction for use. Please follow the information below to ensure long-term trouble-free boiler operation to your and also our satisfaction. -
Page 5: Use And Preferences Of The Boiler
1 USE AND PREFERENCES OF THE BOILER Four-element size of ATTACK FD is suitable for reconstructions of heat sources in dwellings, for smaller flats and recreation facilities. Bigger size of the boiler suits to requirements for heating in family houses, shops, schools and similar. The boiler is produced as a hot-water boiler with natu- ral as well as forced heating water passage and working overpressure up to 4 bar. -
Page 6: Technical Parameters Of Attack Fd Solid Fire
2 TECHNICAL PARAMETERS OF ATTACK FD SOLID FIRE Boiler type Unit FD20 FD26 FD32 FD36 FD42 Number of elements Nominal output – black coal* Nominal output – wood** Fuel consumption at nominal output – black coal* Volume of combustion chamber – black... -
Page 7: Dimensions Of Boilers Attack Fd Solid Fire
3 DIMENSIONS OF BOILERS ATTACK FD SOLID FIRE M - C.H. passage 2’’ R - C.H. return 2’’ S - Boiler drain ½’’ 4 HEAD LOSSES... -
Page 8: Description
5 DESCRIPTION Boiler construction The main part of the boiler is a cast-iron - element boiler body produced of grey cast iron ac- cording to STN EN 1561 - middle elements – quality 150 - front and rear elements – quality 200 Pressure parts of the boiler suit to the requirements for tightness by standards: STN EN 303-5:2000 Boilers for Central Heating, Part 5: Boiler for central heating for solid fuel with manual or automatic delivery with nominal output up to 300 kW terminology, requirements,... -
Page 9: Location And Installation Of The Boiler Attack Fd Solid Fire
Possibilities of location The boiler ATTACK FS is certified for installation in non-residential spaces (cellar, halls, etc.) ac- cording to Notice 84/1997m) appendix, no. 2, 3, 4, 5, 6, 7, 8, 9, 10 – these appendixes are the part... -
Page 10: Boiler Location According To Fire Safety Regulations
6.1 BOILER LOCATION ACCORDING TO FIRE SAFETY REGULATIONS 1. Location on a floor of an incombustible material • Put the boiler on an incombustible pad exceeding dimensions of the lateral sides of the boiler in 20 mm and only for the lenght of combustion chamber •... -
Page 11: Supply And Packaging
The opening should be situated in the lower part of an outer wall, preferably opposite the com- bustion gas discharge. Flue connection A flue should correspond to the following parameters: • it should be from waterproof materials resistant to the temperature of smokes and conden- sations, •... -
Page 12: Appliance For Excessive Heat Removal - Cooling Circuit
WARNING: For admitting claim there must be used a cooling circle and thermoregulation circle with ATTACK FD SOLID FIRE boiler used in closed ventilation system. A cooling circuit serves to excessive heat removal so that the highest water temperature 110°C in the boiler was not overreached. -
Page 13: Dimensions Of Cooling Circuit
9.1 DIMENSIONS OF COOLING CIRCUIT 10 BOILER ASSEMBLY Set the boiler body on the place, connect heating and return water with the help of flanges with the G2" internal thread. To the outlet of heating water in the upper part of the boiler body, ad- just a pipe on the G2 thread and a cooling loop on the pipe, then connect to the heating system. -
Page 14: Casing Assembly
11.1 CASING ASSEMBLY Two superior tie rods are screwed on three nuts at the front side of the boiler: the second and the third nut serve to place correctly the lateral sides of the casing. Two nuts, one for fixing the clamp holders for the lateral sides are screwed on the inferior tie rods, both form the front side and from the rear side. -
Page 15: Draught Regulator
12 DRAUGHT REGULATOR Draught regulator – the thermostatic regulator is equipped with a thermostatic head adjustable between 30 and 100 ° C. Screw the regulator into the ¾" opening of the front head and put it with red index on the upper part. -
Page 16: Attendance Of The Boiler By A User
• During the heating period it is necessary to keep constant volume of water in the heating system. When refilling the heating set with water it is necessary to avoid sucking the air in the system. Water from the boiler and heating system must never by drained or taken for use except for unavoidable situations such as repairs and so on. - Page 17 9. After inflaming it, load other dose of fuel up to the bottom edge of a load port and arrange the fuel into an even layer. 10. As soon as fuel gets deep red glare, open a little the air disk of secondary air inlet on the load port by means of a tool.
-
Page 18: Maintenance
Longtime interruption of the operation For longtime interruption of the operation (e.g. end of heating season) clean the boiler properly, so as moisture causing excessive corrosion is not kept in soot and ash. IMPORTANT WARNING: 1. Attendance of the boiler can be only carried out by adults familier with this instruction. To leave children without a supervision of adults near the boiler is not allowed. -
Page 19: Instructions For Product Liquidation After Its Service Life
16 INSTRUCTIONS FOR PRODUCT LIQUIDATION AFTER ITS SERVICE LIFE As this product is made of common metal materials , we recommend to liquidate single parts in this way: • heat exchanger (grey cast iron) – by a company dealing with collection and liquidation of waste •... -
Page 20: Repairs
18 REPAIRS A person performing the attendance of the boiler can carry out only the repairs consisting of simple exchange of parts like packing cord. Other necessary defects can be only removed by a service company from the list that is delivered as a supplement of the instructions for use. For the repairs, use only original spare parts. -
Page 21: Kit For 3 Class Assembly
19 KIT FOR 3 CLASS ASSEMBLY KIT FOR 3 CLASS... -
Page 27: Assembly Procedure
Unpack parts of convertible kit. Check if the composition agree with the size of the boiler. Check if the concrete parts are not damaged. 19.1 ASSEMBLY PROCEDURE Assembly the cover sheet with screws M6x10 – 2 pcs on rear side of boiler. Then assembly flue gas chimney. -
Page 28: Appendixes
20 APPENDIXES Appendixes are attached to the instructions of use. 20.1 APPENDIX NO. 2 Example of protective plate of fuel appliance (dimensions in mm) LEGEND: 1 – protective plate of fuel appliance 2 – feed entrance 3 – opening of ashtray... -
Page 29: Appendix No. 3
20.2 APPENDIX NO. 3 Example of protective plate of fuel appliance (dimensions in mm) LEGEND: 1 – protective plate of fuel appliance 2 – feed entrance 3 – opening of ashtray... -
Page 30: Appendix No 3
20.3 APPENDIX NO 3. Example of non-flammable surface treatment of the wall around the fireplace and the pro- tective plate in front of fireplace (dimensions in mm) LEGENDA: 1 – non-flammable surface treatment of the wall around the fireplace 2 – flammable surface treatment of the wall 3 –... -
Page 31: Appendix No. 5
20.4 APPENDIX NO. 5. Example of positioning of wooden construction near by chimney’s bodies (dimensions in LEGEND: 1 – min. free safe distance - 50 m 2 – safe distance reduced by 10 mm non-flammable thermal insulation 3 – change of beam 4 –... -
Page 32: Appendix No. 6
20.5 APPENDIX NO. 6. Example of production of spark catcher (dimensions in mm) LEGEND: 1 – chimney head cover plate 2 – chimney ventilating hole with chimney insert 3 – spark catcher 20.6 APPENDIX NO. 7. Safe distances between appliances and flue pipes from flammable materials Appliances by fuel type Safe distance and electrothermal appliances... -
Page 33: Appendix No. 8
20.7 APPENDIX NO. 8. Flue gas transmission through a ceiling of flammable materials (dimensions in mm) LEGEND: 1 – ceilling 2 – flue gas ducting 3 – flue gas ducting’s extension 4 – protecting tube (non-flammable) 5 – chimney breast (non-flammable, non- metallic) 6 –... -
Page 34: Appendix No.10
20.9 APPENDIX NO.10. Example of positioning of protective screen of fuel appliance and flue gas ducting (di- mensions in mm) LEGEND: 1 – protective screen of fuel appliance and flue gas ducting protecting surrounding combustible building structures against their thermal effects 2 –... - Page 36 In case of any questions related to the processing of your personal data, please do not hesitate to contact us at tel. no. 00421 43 400 3131 or support@attack.sk. Privacy Manager: ATTACK, s. r. o., with its registered office at Dielenská Kružná 5020, 038 61 Vrútky, Slovak Re- public Tel .: +421 43 4003 101 Fax .: +421 43 3241 129...
- Page 37 your personal data, i. e. direct offer of our products sent to you. 2) The legal basis for fulfilling the extended warranty agreement on the product in which you enter the Boiler Startup Record whereare your personal data is Art. Article 6 1. Letter. (f) Regulation (EU) 2016/679 of the European Parliament and of the Council of 27 April 2016 on the protection of natural persons with regard to the processing of personal data and on the free movement of such data, and repealing Directive 95/46/EC (General Data...
- Page 38 ATTACK, s. r. o., Dielenská Kružná 5020, 038 61 Vrútky, Slovak Republic. In the objection, it is suf- ficient to provide the name, address and the text "I hereby raise an objection to the processing of my personal data for the purposes of direct marketing"...
- Page 39 Guarantee The company ATTACK, s.r.o. warrants for this product only if there have been met conditions of the warranty in time 24 months - 2 years - from the date of starting the boiler up. The serial num. of the boiler:...
- Page 40 - wood pellets of 6 mm diameter, max. length 35 mm, according to DIN 51 731-HP 5 or DIN Plus or EN 14961-2-A1 Regumat ATTACK-OVENTROP will not be installed in the system to ensure that the boiler return temperature is at least 65 ° C during operation there is no functional thermostatic valve installed to the boiler for cooling circuit connected to the cooling wa- ...
- Page 44 All provided information is temporary, subject to change without notice and for informational purposes only. Variations in product visual display are possible and may not match the offer and range of equipment for different markets. ATTACK s.r.o. reserves the right to make changes to specifications and content without prior notice. Pictures and product specifications are...
