Summary of Contents for ATTACK EKO
- Page 1 ATTACK® CAST IRON FLOOR STANDING GAS BOILER EKO, PLQ, KLQ, KLV, E, EZ, P INSTRUCTION FOR USE W W W . A T T A C K . S K...
-
Page 2: Putting The Boiler Into Operation
7. To put the boiler out of operation for a long time, turn the combined valve into the „off“ posi- tion (see instruction EKO, PLQ, P), close the manual gas valve and put the power supply flex out of the socket 230 V/50 Hz. -
Page 3: Table Of Contents
Conditions to keep the ecological parameters ..........................7 Technical description EKO, PLQ, KLV, KLQ, E, EZ, P types ......................7 Electrical front panel of the EKO, PLQ, KLV, KLQ, E boilers ......................8 Electrical front panel of the EZ boilers ............................. 8 External dimensions of the EKO, KLV, PLQ, KLQ, P boilers ...................... -
Page 4: Introduction
PURPOSE OF USE The type line of EKO, KLV boilers is produced with the stable capacity of 9, 12, 15, 20, 25, 30, 35, 40, 45, 49,9 kW. The P type line is produced in the stable capacity of 9, 18, 25, 35, 45, 50 kW. The PLQ, KLQ type ranges are produced in modulated capacity of 6–9, 12–15, 15–20, 18–25, 24–30, 28–35, 38–45,... -
Page 5: Modifications Of The Cast Iron Gas Boilers
Adequately to the project requirements, it is necessary to choose a suitable boiler type and out- put. Therefore we produce boilers in various modifications: ATTACK EKO – floor standing cast iron boiler with permanent flame controlled by a thermocouple. ATTACK PLQ – floor standing cast iron boiler with permanent flame controlled by a thermocou- ple and two-stage output regulation controlled by a switch on the front panel. -
Page 7: Safety Conditions
CAST IRON FLOOR STANDING GAS BOILER If there is a danger of approach of inflammable (explosive) gases or fumes to the boiler (e.g. by PVC application), it must be put out of operation early including the burning flame (EKO, PLQ, P). SAFETY CONDITIONS When installing a boiler, a safe distance of its surface from inflammable materials depending on... -
Page 8: Electrical Front Panel Of The Eko, Plq, Klv, Klq, E Boilers
Due to this is the regulation screw painted. Under the valve there is a holder on the gas distributor (EKO, PLQ, P) with a piezoelectric ignitor used for starting the ignition burner. Above the valve near the upper edge of the front door there is a covered electroinstallation board with all the electroinstallation. -
Page 11: Connecting The Boiler To The Electricity Mains (Not For Attack P Boilers)
230 V is out of operation which means that a valve closes gas flow to the burners. The flame of ignition burner (EKO, PLQ, P) is still burns and the boiler stays in a stand- by mode. -
Page 12: Stop - Putting The Boiler Out Of Operation
The valve closes because of losing the voltage and the gas supply is interrupted y the flame of ignition burner still burns, the boiler is in a stand-by mode (EKO, PLQ, P) y in the case of need, put the boiler into operation by switching the main switch on... -
Page 13: Failure States Of Operation
CAST IRON FLOOR STANDING GAS BOILER FAILURE STATES OF OPERATION When these occur, the gas supply into the main burner and ignition burner is automatically closed: y when the thermo-couple (ionisation electrode) is cooled because of: gas supply breakdown, clogging by dirts, the flame extinguished by condensate, wrong setting of the thermo-couple with reference to the ignition burner, y when there is breakdown in the circuit of the boiler thermostat, the water in the boiler body gets overheated. -
Page 14: Chimney Draught Breaker
The boiler is equipped with the basic regulation and control elements that serve for one-level (EKO, KLV), two-level (PLQ, KLQ) and automatically controlled (E, EZ) output regulation. The regula- tion of the boiler can be set up and controlled only by a specialized service worker. -
Page 15: After Set Up
The boiler works adequately to the selected mode. After reaching the required temperature of heating water, the flame on burners extinguishes and only the ignition burner burns (EKO, PLQ, P). After it gets colder, the flame is ignited automatically. With this way of regulation the cycles (on-off) of the boiler change often, mainly in the transient times of seasons when the heating water tem- perature is low, and there is excess output. -
Page 16: Guarantee, Claim
+50°C and maximum relative humidity of air of 75 %, without any organic steams, gases and dust. BOILER ACCESSORIES AND DOCUMENTATION The ATTACK EKO, PLQ, KLQ, KLV, E, EZ, B boilers are delivered completely assembled and func- tionally tested. The delivery contains the following documentation: y instruction manual together with a document boiler test certificate on its back side... -
Page 17: Setting Of The Modulation Electronics Of The Attack Ez Boiler
Appliance category: I Boiler design: B11BS Connection overpressure of natural gas G20: 20 mbar SETTING OF THE MODULATION ELECTRONICS OF THE ATTACK EZ BOILER 1. Trimmers P1 – CH. CAPACITY – setting of the max. boiler output into the heating system P2 –... -
Page 18: Technical Data
— 27,5–38,5 — 33–49,5 36,3–55 Gas pressure in front of the boiler mbar Diameter of nozzles Pressure to nozzles – EKO, PLQ, 0,8–1,4 0,95 0,7–1,05 0,8–1,2 0,8–1,35 1–1,35 0,7–1,15 1,35 0,85–1,15 0,85–1,25 KLV, KLQ, P Pressure to nozzles – E, EZ 0,8–1,4... -
Page 19: Connecting The Electrical Installation Of The Attack Eko Boiler
CAST IRON FLOOR STANDING GAS BOILER Connecting the electrical installation of the ATTACK EKO boiler ATTENTION: Connect the TP (room ther- & mostat), eventually the TV (three-way valve) as well into the terminals 7 and 8. PUMP ý(53$'/2 Remove the interconnection! -
Page 20: Connecting The Electrical Installation Of The Attack Plq Boiler
Connecting the electrical installation of the ATTACK PLQ boiler ATTENTION: Connect the TP (room ther- mostat), eventually the TV & (three-way valve) as well into the terminals 7 and 8. PUMP ý(53$'/2 Remove the interconnection! Interconnection a 9 +] 2ý... -
Page 21: Connecting The Electrical Installation Of The Attack Ez Boiler
CAST IRON FLOOR STANDING GAS BOILER Connecting the electrical installation of the ATTACK EZ boiler Mains switch Boiler thermostat Potentiometer Terminal 5 ± N: ]å ]å Filter þ þ ]å Sensor of the tank Connector of Sensor of þ... - Page 22 In case of any questions related to the processing of your personal data, please do not hesitate to contact us at tel. no. 421 43 400 310 or gdpr@attack.sk. Privacy Manager: ATTACK, s. r. o., with its registered office at Dielenská Kružná 5020, 038 61 Vrútky, Slovak Republic Tel .: +421 43 4003 10 E-mail: export @attack.sk...
- Page 23 your personal data, i. e. direct offer of our products sent to you. 2) The legal basis for fulfilling the extended warranty agreement on the product in which you enter the Boiler Startup Record whereare your personal data is Art. Article 6 1. Letter. (f) Regulation (EU) 2016/679 of the European Parliament and of the Council of 27 April 2016 on the protection of natural persons with regard to the processing of personal data and on the free movement of such data, and repealing Directive 95/46/EC (General Data...
- Page 24 ATTACK, s. r. o., Dielenská Kružná 5020, 038 61 Vrútky, Slovak Republic. In the objection, it is suf- ficient to provide the name, address and the text "I hereby raise an objection to the processing of my personal data for the purposes of direct marketing"...
- Page 28 Tel: +421 43 4003 101 • Fax: +421 43 3241 129 • E-mail: kotle@attack.sk Export – tel: +421 43 4003 115 • Fax: +421 43 3241 129 • E-mail: export@attack.sk ATTACK, s.r.o. producer reserves the right to change technical parameters and dimensions of boilers without previous warning.
