Available settings are explained as follows:
Item
Enable
Display Name
Physical Mode
Physical Type
VLAN Tag insertion
After finished the above settings, click OK to save the settings.
4 . 1 . 3 I n t e r n e t A c
4 . 1 . 3 I n t e r n e t A c
This page allows you to configure the access mode for building Internet connection.
Available settings are explained as follows:
Description
Choose Yes to invoke the settings for this WAN interface.
Choose No to disable the settings for this WAN interface.
Type the description for such WAN interface.
Display the physical mode of such WAN interface.
You can change the physical type for WAN or choose Auto
negotiation for determined by the system.
Enable – Enable the function of VLAN with tag.
The router will add specific VLAN number to all packets on
the WAN while sending them out.
Please type the tag value and specify the priority for the
packets sending by WAN1.
Disable – Disable the function of VLAN with tag.
Tag value – Type the value as the VLAN ID number. The
range is form 0 to 4095.
Priority – Type the packet priority number for such VLAN.
The range is from 0 to 7.
c e s s
c e s s
135
Vigor2132 Series User's Guide
