Internet Access Control
LAN Access Control
Access List from the
Internet
Management Port Setup
TLS/SSL Encryption
Setup
After finished the above settings, click OK to save the configuration.
Vigor2132 Series User's Guide
The web user interface will be open until you click the
Logout icon manually.
Allow management from the Internet - Enable the
checkbox to allow system administrators to login from the
Internet. There are several servers provided by the system to
allow you managing the router from Internet. Check the
box(es) to specify.
Disable PING from the Internet - Check the checkbox to
reject all PING packets from the Internet. For security issue,
this function is enabled by default.
Allow management from LAN- Enable the checkbox to
allow system administrators to login from LAN interface.
There are several servers provided by the system which
allow you to manage the router from LAN interface. Check
the box(es) to specify.
Apply To Subnet – Check the interface for the
administrator to use for accessing into web user interface of
Vigor router.
You could specify that the system administrator can only
login from a specific host or network defined in the list. A
maximum of three IPs/subnet masks is allowed.
List IP - Indicate an IP address allowed to login to the
router.
Subnet Mask - Represent a subnet mask allowed to login to
the router.
User Define Ports - Check to specify user-defined port
numbers for the Telnet, HTTP, HTTPS, FTP, TR-069 and
SSH servers.
Default Ports - Check to use standard port numbers for the
Telnet and HTTP servers.
Enable SSL 3.0 – Check the box to enable the function of
SSL 3.0 if required.
Due to security consideration, the built-in HTTPS and SSL
VPN server of the router had upgraded to TLS1.x protocol.
If you are using old browser(e.g. IE6.0) or old SmartVPN
Client, you may still need to enable SSL 3.0 to make sure
you can connect, however, it's not recommended.
