WPA
WEP
Vigor2132 Series User's Guide
Note: You should also set RADIUS Server simultaneously
if 802.1x mode is selected.
Disable - Turn off the encryption mechanism.
WEP-Accepts only WEP clients and the encryption key
should be entered in WEP Key.
WEP/802.1x Only - Accepts only WEP clients and the
encryption key is obtained dynamically from RADIUS
server with 802.1X protocol.
WPA/802.1x Only- Accepts only WPA clients and the
encryption key is obtained dynamically from RADIUS
server with 802.1X protocol.
WPA2/802.1x Only- Accepts only WPA2 clients and the
encryption key is obtained dynamically from RADIUS
server with 802.1X protocol.
Mixed (WPA+WPA2/802.1x only) - Accepts WPA and
WPA2 clients simultaneously and the encryption key is
obtained dynamically from RADIUS server with 802.1X
protocol.
WPA/PSK-Accepts only WPA clients and the encryption
key should be entered in PSK.
WPA2/PSK-Accepts only WPA2 clients and the
encryption key should be entered in PSK.
Mixed (WPA+ WPA2)/PSK - Accepts WPA and WPA2
clients simultaneously and the encryption key should be
entered in PSK.
The WPA encrypts each frame transmitted from the radio
using the key, which either PSK (Pre-Shared Key) entered
manually in this field below or automatically negotiated via
802.1x authentication. Either 8~63 ASCII characters, such
as 012345678(or 64 Hexadecimal digits leading by 0x, such
as "0x321253abcde...").
Type - Select from Mixed (WPA+WPA2) or WPA2 only.
Pre-Shared Key (PSK) - Either 8~63 ASCII characters,
such as 012345678..(or 64 Hexadecimal digits leading by
0x, such as "0x321253abcde...").
64-Bit - For 64 bits WEP key, either 5 ASCII characters,
such as 12345 (or 10 hexadecimal digitals leading by 0x,
such as 0x4142434445.)
128-Bit - For 128 bits WEP key, either 13 ASCII
characters, such as ABCDEFGHIJKLM (or 26 hexadecimal
digits leading by 0x, such as
0x4142434445464748494A4B4C4D).
All wireless devices must support the same WEP encryption
bit size and have the same key. Four keys can be entered
here, but only one key can be selected at a time. The keys
can be entered in ASCII or Hexadecimal. Check the key
354
