Draytek Vigor2132 Series User Manual page 222

Available settings are explained as follows:
Item
Check to enable the Filter
Rule
Comments
Index(1-15)
Clear sessions when
schedule ON
Direction
Source/Destination IP
Vigor2132 Series User's Guide
Description
Check this box to enable the filter rule.
Enter filter set comments/description. Maximum length is
14- character long.
Set PCs on LAN to work at certain time interval only. You
may choose up to 4 schedules out of the 15 schedules
pre-defined in Applications >> Schedule setup. The
default setting of this field is blank and the function will
always work.
Check this box to clear the sessions when the above
schedule profiles are applied.
Set the direction of packet flow. It is for Data Filter only.
For the Call Filter, this setting is not available since Call
Filter is only applied to outgoing traffic.
Note: RT means routing domain for 2nd subnet or other
LAN.
Click Edit to access into the following dialog to choose the
source/destination IP or IP ranges.
214
