Available settings are explained as follows:
Item
Multi-VLAN Channel
8/9/10
General Settings
Bridge mode
Moreover, WAN link for Channel 5, 6 and 7 are provided for router-borne application such as
TR-069. The settings must be applied and obtained from your ISP. For your special request,
please contact with your ISP and then click WAN link of Channel 5, 6 or 7 to configure your
router.
Vigor2132 Series User's Guide
Description
Enable – Click it to enable the configuration of this
channel.
Disable –Click it to disable the configuration of this
channel.
VLAN Tag – Type the value as the VLAN ID number.
Valid settings are in the range from 1 to 4095. The network
traffic flowing on each channel will be identified by the
system via their VLAN Tags. Channels using the same
WAN type may not configure the same VLAN tag value.
Priority – Choose the number to determine the packet
priority for such VLAN. The range is from 0 to 7.
Enable – Click it to enable Bridge mode for such channel.
Physical Members – Group the physical ports by checking
the corresponding check box(es) for applying the bridge
connection.
