1 . 2 . 2 V i g o r 2 1 3 2 a
1 . 2 . 2 V i g o r 2 1 3 2 a
LED
ACT (Activity)
USB1~USB2
WAN
2.4G/5G
CSM
DoS
QoS
Phone1 ~ Phone2
LED on Connector
Left
WAN
LED
Right
LED
Left
LAN1~
LED
LAN4
Right
LED
c / V a c
c / V a c
Status
Blinking
Off
On
Blinking
On
Off
Blinking
On
Blinking
On
On
Blinking
On
On
Off
Blinking
On
Off
Blinking
On
Off
On
Off
Blinking
On
Off
Explanation
The router is powered on and running normally.
The router is powered off.
USB device is connected and ready for use.
The data is transmitting.
Internet connection is ready.
Internet connection is not ready.
The data is transmitting.
Wireless access point with bandwidth of 2.4GHz/5GHz
is ready.
It will blink slowly while wireless traffic goes through.
ACT and WLAN LEDs blink quickly and
simultaneously when WPS is working, and will return
to normal condition after two minutes. (You need to
setup WPS within 2 minutes.)
The profile(s) of CSM (Content Security Management)
for IM/P2P, URL/Web Content Filter application can
be enabled from Firewall >>General Setup. (Such
profile must be established under CSM menu).
The DoS function is active.
It will blink while detecting an attack.
The QoS function is active.
The phone connected to this port is off-hook.
The phone connected to this port is on-hook.
A phone call comes.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 1000Mbps.
The port is connected with 10/100Mbps
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 1000Mbps.
The port is connected with 10/100Mbps
5
