Draytek Vigor2132 Series User Manual page 346

Act as Outbound Proxy
Display Name
Account Number/Name
Authentication ID
Password
Expiry Time
NAT Traversal Support
Call Forwarding
Vigor2132 Series User's Guide
time you can type :port number after the domain name to
specify that port as the destination of data transmission
(e.g., nat.draytel.org:5065)
Check this box to make the proxy acting as outbound proxy.
The caller-ID that you want to be displayed on your friend's
screen.
Enter your account name of SIP Address, e.g. every text
before @.
Check the box to invoke this function and enter the name or
number used for SIP Authorization with SIP Registrar. If
this setting value is the same as Account Name, it is not
necessary for you to check the box and set any value in this
field.
The password provided to you when you registered with a
SIP service.
The time duration that your SIP Registrar server keeps your
registration record. Before the time expires, the router will
send another register request to SIP Registrar again.
If the router (e.g., broadband router) you use connects to
internet by other device, you have to set this function for
your necessity.
None – Disable this function.
Stun – Choose this option if there is Stun server provided
for your router.
Manual – Choose this option if you want to specify an
external IP address as the NAT transversal support.
Nortel – If the soft-switch that you use supports Nortel
solution, you can choose this option.
There are four options for you to choose. Disable is to close
call forwarding function. Always means all the incoming
calls will be forwarded into SIP URL without any reason.
Busy means the incoming calls will be forwarded into SIP
URL only when the local system is busy. No Answer
means if the incoming calls do not receive any response,
they will be forwarded to the SIP URL by the time out.
SIP URL – Type in the SIP URL (e.g., aaa@draytel.org or
338
