Draytek Vigor2132 Series User Manual page 164

Open WAN Interface for
this Channel
ISP Access Setup, IP
Address From ISP, WAN
IP Network Settings, DNS
Server IP Address
After finished the above settings, click OK to save the settings.
Vigor2132 Series User's Guide
using the VLAN tag configured.
Physical Members – Group the physical ports by checking
the corresponding check box(es) for applying the port-based
bridge connection.
Check the box to enable relating function.
WAN Application - Management can be specified for
general management (Web configuration/telnet/TR069). If
you choose Management, the configuration for this VLAN
will be effective for Web configuration/telnet/TR069.
IPTV - The IPTV configuration will allow the WAN
interface to send IGMP packets to IPTV servers.
WAN Setup – Choose PPPoE/PPPoA or Static or
Dynamic IP to determine what WAN settings must be
configured.
For other settings, refer to Details Page for PPPoE in
WAN1.
156
