4 . 4 . 5 A L G
4 . 4 . 5 A L G
ALG means Application Layer Gateway. There are two methods provided by Vigor router,
RTSP (Real Time Streaming Protocol) ALG and SIP (Session Initiation Protocol) ALG, for
processing the packets of voice and video.
RTSP ALG makes RTSP message, RTCP message, and RTP packets of voice and video be
transmitted and received correctly via NAT by Vigor router.
However, SIP ALG makes SIP message and RTP packets of voice be transmitted and received
correctly via NAT by Vigor router.
Available settings are explained as follows:
Item
Enable ALG
Listen Port
TCP
UDP
Description
Check to enable such function.
Type a port number for SIP or RTSP protocol.
Check the box to make correspond protocol message packet
from TCP transmit and receive via NAT.
Check the box to make correspond protocol message packet
from UDP transmit and receive via NAT.
203
Vigor2132 Series User's Guide
