Available settings are explained as follows:
Item
Multi-VLAN Channel
5/6/7
General Settings
Open Port-based Bridge
Connection for this
Channel
Description
Enable – Click it to enable the configuration of this
channel.
Disable –Click it to disable the configuration of this
channel.
VLAN Tag – Type the value as the VLAN ID number.
Valid settings are in the range from 1 to 4095. The network
traffic flowing on each channel will be identified by the
system via their VLAN Tags. Channels using the same
WAN type may not configure the same VLAN tag value.
Priority – Choose the number to determine the packet
priority for such VLAN. The range is from 0 to 7.
The settings here will create a bridge between the LAN
ports selected and the WAN. The WAN interface of the
bridge connection will be built upon the WAN type selected
155
Vigor2132 Series User's Guide
