Draytek Vigor2132 Series User Manual page 344

Available settings are explained as follows:
Item
Index
Profile
Domain/Realm
Proxy
Account Name
Codec
Ring Port
Status
STUN Server
External IP
SIP PING interval
Vigor2132 Series User's Guide
Description
Click this link to access into next page for setting SIP
account.
Display the profile name of the account.
Display the domain name or IP address of the SIP registrar
server.
Display the domain name or IP address of the SIP proxy
server.
Display the account name of SIP address before @.
Display the codec type for the account.
Specify which port will ring when receiving a phone call.
Show the status for the corresponding SIP account. R
means such account is registered on SIP server
successfully. – means the account is failed to register on
SIP server.
Type in the IP address or domain of the STUN server.
Type in the gateway IP address.
The default value is 150 (sec). It is useful for a Nortel
server NAT Traversal Support.
336
