SPECIFICATIONS

■ General

• Minimum range:
• Maximum range:
• Measurement range:
• Preheat time:
• Connection length between display and scanner unit: 15 m; 49.2 ft (MR-1210RII),

■ Display unit

• LCD display:
• Pixels:
• LCD mounting:
• Input:
• Output:
• Power supply requirement:
• Power consumption (at zero wind velocity):
• Usable temperature range:
• Dimensions (Mounting bracket is included):
(Projections are not included)
• Weight (Mounting bracket is included):

■ Scanner unit

D EX-2714 (Radome)
• Type:
• Rotation speed (typical):
• Beam width (typical):
• Side lobe (typical):
• Polarization:
• Transmission frequency:
• Peak output power:
• Pulse width:
• Mixer and Local Oscillator:
• Transmitting Tube:
• Modulator:
• Duplexer:
• Tuning system:
• Intermediate frequency:
• IF Band width:
• Dimensions:
• Usable temperature range:
• Relative Humidity:
• Weight:
61
25 m; 82 ft (when measurement range is
36 NM (MR-1210RII; when measurement range is 36 NM)
48 NM (MR-1210TII; when measurement range is 48 NM)
72 NM (MR-1210TIII; when measurement range is 72 NM)
1 ⁄ , 1 ⁄ , 1 ⁄ , 3 ⁄ , 1, 1.5, 2, 3, 4, 6, 8, 12, 16, 24, 32, 36, 48*
8 4 2 4
64* 2 , 72* 2 (NM) * 1 only MR-1210TII/TIII, *
90 seconds
20 m; 65.6 ft (MR-1210TII/TIII, optional for MR-1210RII),
30 m; 98.4 ft (optional)
12.1-inch TFT Color LCD display
600×800 dot
Vertical
NMEA 0183 format (for navigation receiver),
N+1 format (fluxgate compass sensor),
AUX,
IEC61162-2 format (for AIS unit)
NMEA 0183 format
10.2 to 42 V DC
Approximately 60 W (MR-1210RII)
Approximately 70 W (MR-1210TII #11,12)
Approximately 80 W (MR-1210TII #16,17, MR-1210TIII #21, 22)
Approximately 90 W (MR-1210TIII #31, 32)
–15˚C to +55˚C; +5˚F to 131˚F
300 (W)×323 (H)×119.2 (D) mm,
11.8 (W)×12.7 (H)×4.7 (D) in
Approximately 4.6 kg; 10.1 lb
60 cm (2 ft.) Slotted Waveguide Array,
enclosed in a radome.
24 rpm, 36 rpm
Horizontal beam 4˚
Vertical beam 22˚
–22 dB
Horizontal
9410 MHz ±30 MHz P0N
4 kW
80 ns/2160 Hz, 80 ns/1440 Hz, 250 ns/1440 Hz,
350 ns/1440 Hz, 900 ns/720 Hz
Microwave Integrated Circuit
Magnetron MAF1421B
FET switching
Circulator
Automatic/manual selectable
60 MHz
10 MHz, 3 MHz
640 (W)×256 (H)×640 (D) mm,
25.2 (W)×10.1 (H)×25.2 (D) in
–25˚C to +70˚C; –13˚F to 158˚F
Less than 95% at 40˚C (+104˚F)
Approximately 8 kg; 17.5 lb (without cable)
1 ⁄ NM)
8
1 ,
2 MR-1210TIII
