Icom MR-1210RII Instruction Manual page 16

2
MENU SCREEN
■ System menu (Continued)
D Zone Alarm1
D Zone Alarm2
Sets the Zone Alarm1 and Zone Alarm2 settings.
• IN: An alarm sounds when the target comes into
the zone.
• OUT: An alarm sounds when the target goes out of
the zone.
D Zone Alarm Level
Selects the target detection parameter of zone alarm
1 and 2.
Selectable parameters are Low, Middle and High.
D OFF Center Mode
Sets the OFF Center setting when the OFF Center
function is ON.
• 25, 50, 75%: The center of the display area moves
to the front of the bow, and the bow
view increases.
• Cursor: The center of the display area shifts
to the cursor, and the opposite view
increases.
D Save Time
Selects the standby time during the save mode from 1
min, 6 min, 15 min or 30 min.
• The radar for a TX interval scan is fixed at 10 revolutions.
D Bearing Mode
Select the displayed bearing type, regardless of the
bearing data format (NMEA, N+1, AUX, GPS, or GPS-L).
• True: Select the true North bearing.
• Magnetic: Select the magnetic North bearing.
D Variation
Selects the difference setting between true North and
magnetic North.
• Auto: Automatically revises the magnetic variations.
Until an effective variation is received, use
0° for difference between true North and
magnetic North. After an effective variation
is received, use the last data for the differ-
ence. The MR-1210 memorize the data un-
til you turn OFF the power.
• Manual: Manually revises the magnetic variation.
Use the manual setting for the difference
between true North and magnetic North.
Set the Manual Variation in the next item.
D Manual Variation
Manually sets the difference between true North and
magnetic North. Selectable angles are 180.0°W (West)
to 180°E (East).
This setting is used when "Variation" is set to "Manual."
11
D Bearing Reference
Sets the direction for the EBL (Electronic Bearing Line)
or cursor.
• True: True or magnetic direction
• 360°R: Relative direction
• PT/SB: Bow direction
D Speed Input
Selects the speed input of the vessel from "SOG" or
"Manual." If you select "Manual," enter data manually
into the items below, "Manual Speed", "Manual SET",
and "Manual Drift."
D Manual Speed
Sets your vesselʼs speed to between 0.1 and 40.0 kn.
(0.2 ~ 74.0km/h, 0.1 ~ 46.0 mph)
D Manual SET
Sets the Tidal current direction to between 0 and
359.9°T (or M).
D Manual Drift
Sets the Tidal current speed to between 0 and 20.0 kn.
(0 ~ 37.0 km/h, 0 ~ 23.0 mph)
D TLL Mode
• Output: Hold down [MENU]/[
output the position information where the
cursor is positioned, to the NMEA output
terminals.
• Symbol: Hold down [MENU]/[
mark on the screen where the cursor is po-
sitioned.
• Output & Symbol:
Hold down [MENU]/[
output the position information and mark on
the screen where the cursor is positioned.
D Transparency Menu
Sets the transparency level of the Menu screen and
Brilliance/Color dialog box to between 0% (Nontrans-
parent) and 70% (Transparent).
D Transparency Info.
Sets the transparency level of the Information box,
Own Ship information box, Cursor information box or
Range/COG/Tune tag to between 0% (Nontranspar-
ent) and 70% (Transparent).
D STBY Mode
Sets the display information in the Standby mode to
Normal or AIS.
D Rev.
Displays the revision number of the firmware.
] for 1 second to
] for 1 second to
] for 1 second to
