INSTRUCTION MANUAL
MARINE RADAR
MR-570R
This device complies with Part 15 of the FCC rules. Opera-
tion is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
Advertisement
Related Manuals for Icom MR-570R
Summary of Contents for Icom MR-570R
- Page 1 INSTRUCTION MANUAL MARINE RADAR MR-570R This device complies with Part 15 of the FCC rules. Opera- tion is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that...
- Page 2 Installation nuts (M10) ......... 4 t Flat washers (M10) ..........4 y Spring washers (M10) ......... 4 Icom, Icom Inc. and the logo are registered trademarks of Icom Incorporated (Japan) in the United states, the United Kingdom, Germany, France, Spain, Russia and/or other countries.
- Page 3 *See the [ADJ] menu on p. 6. surfaces. FOREWORD Thank you for purchasing ICOM’s MR-570R MARINE RADAR. The radar is designed especially for fishing boats. It has powerful transmission power, a 5.7 inch LCD dis- play and many other advanced features.
- Page 4 TABLE OF CONTENTS I Minimum range ..........24 SYSTEM COMPONENTS...........i I Blind and Shadow sectors ....... 25 SUPPLIED ACCESSORIES........i I Target resolution..........25 IMPORTANT ............. ii PRECAUTIONS ............ii 9 INSTALLATION AND CONNECTIONS ..26–30 I Connecting the units ........26 FOREWORD ............
- Page 5 CAUTION The MR-570R is supplemental aids to navigation and are not intended to be a substitute for accurate and current nautical charts. DANGER! HIGH VOLTAGE • NEVER OPEN THE UNIT This product contains high voltage that could be FATAL. This product has no user-servicable parts inside.
- Page 6 PANEL DESCRIPTION I Front panel Control panel MARINE RADAR q POWER SWITCH [POWER] (p. 10) r MAN OVERBOARD [MOB] Turns power ON and OFF. Push to mark the man overboard point on the • The standby screen appears for 90 sec. while warming screen.
- Page 7 PANEL DESCRIPTION i TRANSMIT/SAVE SWITCH [TX (SAVE)] (p. 11) !5 MODE SWITCH [MODE] Push to toggle between the TX mode and the Push to select one of Head-up (H UP), Course-up standby mode. (C UP), North-up (N UP) or True motion (TM) Push and hold for 0.5 sec.
- Page 8 PANEL DESCRIPTION I Screen 2530˚ NOTE: DATA display area may differ de- S0672˚ 1.296NM O:01 EBL/VRM1 pending on DATA DISP selection in S0162˚ 0.566NM O:01 EBL/VRM2 the FUNCTION menu. !9 TUNING LEVEL INDICATOR @6 EBL1/VRM1,EBL2/VRM2 READOUTS (pgs. 16- Shows the receiver tuning level. Shows the bearing of the displayed Electronic Bear- @0 SCREEN RANGE READOUT (p.
- Page 9 PANEL DESCRIPTION #0 EBL1/2 (pgs. 16-18) • When “CURS” or “SHIP” is selected; Used for bearing measurement. When a target is selected, the EBL readout #6 shows the bearing. #1 VRM1/2 (pgs. 16-18) 0398º 2.068NM O:09 CURS Used for distance measurement. When a target is selected, the VRM2 readout @8 shows the distance.
- Page 10 A-6074H-1US-q Printed in Japan 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003 Japan © 2001, 2002 Icom Inc.
