G 2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - CODED PANEL B
DESCRIPTION OF THE SOUND MODULE

Description of the vocal synthesis (audible signals on the door panel):

Audible signals on the door panel.
If vocal synthesis is enabled on the sound module (see page 19 and 21 for configuration), the following voice
messages can be heard on the door panel:
- While calling: 'Call is in progress'.
- During door release: 'Door Opened!'.
- End of communication: 'Communication is finished'.
- Calling at one door panel while another door panel is communicating (if there is more than one door
panel): 'System is busy, try later'.
- While calling and the monitor is in 'Do not disturb' mode: 'Call is in progress'.
- While calling (apartment with no monitor or telephone): 'Resident Unavailable'.

Selecting the sound module operating mode:

To change the operating mode of the sound module, follow these steps:
- Disconnect the door panel's power supply.
- Set DIP 6 on the sound module (see page 6) to OFF.
- Reconnect the door panel's power supply.
- Set DIP 6 to ON.
- Press and hold down button P1 on the sound module for 6 seconds (until the confirmation
tones end).
- Then continue pressing to change the operating mode indicated by the visual alert LEDs of the door panel 'carousel
mode' (see the following operating mode selection table). Once the required operating mode is selected, stop
pressing button P1.
- Finally, set DIP 6 to OFF. A confirmation tone will be heard and the visual alert LEDs of the door panel will turn off.
Mode
( )
( )
House
1 *
Building
(Up to 32 monitors/telephones)
Building 'tel. only'
(Up to 128 telephones)
Building 'router'
( )
2
(Up to 128 monitors/telephones)
( ) Building 'gateway'
2
(Up to 128 monitors/telephones)
Building
(Up to 32 monitors/telephones)
Building 'tel. only'
(Up to 128 telephones)
Building 'router'
( )
2
(Up to 256 monitors/telephones)
Building 'gateway'
( )
2
(Up to 256 monitors/telephones)
( )
House mode. See the manual enclosed with the corresponding GB2 house kit.
1
( )
2 Building mode 'router'/'gateway'. See the manual enclosed with the RD-GB2/A module.
( )
Sound module configured with
*
Operating modes
Function
Dip4 mode
( )
OFF 1
*
( )
ON 1
*
ON 2
ON 3
ON 4
5
ON
ON 6
7
ON
ON 8
Mode 9 to 12 (no function)
default setting
Door
panel
Instal a l tio n
Buttons Video panel
Video panel/
Buttons
Audio panel
Buttons Audio panel
Video panel
Buttons
(Inst. with risers)
Video panel
Buttons
(Gen panel inst.) .
Video panel/
Coded
Audio panel
Audio panel
Coded
Video panel
Coded
(Inst. with risers)
Video panel
Coded
(Gen. panel inst.)
: house mode and operating mode 1.
LED LED LED
ON OFF OFF
ON OFF OFF
OFF ON OFF
ON ON OFF
OFF OFF ON
ON OFF ON
OFF ON ON
ON ON ON
OFF OFF OFF
------ ------ ------
Continued overleaf
7
P1
LED
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
ON
------
