G 2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - CODED PANEL B

WIRING DIAGRAMS

Video door entry system with 23 VESTA2 monitors, 12 D2L-GB2 distributors and Golmar DC lock release.
( ) 3 ( )
APARTMENT 23
**
( ) 3 ( )
APARTMENT 4
**
( ) 3 ( )
APARTMENT 2
**
Distances and cross-sections:
D2L- GB 2
VESTA2 VESTA2
C C
B
FA- GB /A 2
( )
A
D
(1) Leave the jumper in this position
for 4,3" GB2 monitors of all of the
D2L-GB2 distributors.
( ) Remove the jumper from all
*
of the distributors except
the last.
( )
Configure the end of line in
**
the last monitor.
DIP 6 to ON.
Important:
( ) 2 For the connection of an AC lock release or a 2nd lock release, see page 38.
( ) 3
For more information about the VESTA2 monitor, see the Quick Guide enclosed with its corresponding product.
4 ( )
Distances with Golmar
VESTA2
Master
VESTA2
Master
VESTA2
Master
Cable
2
Twisted pair 2x0.75mm
4
RAP-2150 (twisted pair 2x1mm )
+
12Vdc
(2)
Lock release
max. 12 Vdc/270mA.
RAP-2150 cable (twisted pair 2x1mm ).
VESTA2
( ) 3 ( )
APARTMENT 3
**
VESTA2
( ) 3 ( )
APARTMENT 1
**
100~240Vac
A B C D
60m 60m 30m 10m
2 80m 80m 40m 15m
Access panel
SW1
ON
1 2 3 4 5 6
_
C1 NA1 AP- AP+ NA2 C2 AP+ AP- P1 P2 BUSBUS
Relay 1 Relay 2
(2)
2
(1)
Master
(1)
Master
(1)
Mains
N L L
CN
FA- GB /A 2
BUS (M) BUS(PL)
AP
35
( )
End of line
*
ON
End of line
OFF
End of line
OFF
