G 2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - CODED PANEL
B
DESCRIPTION OF THE TFT SCREEN MODULE
Description of the EL3422/GB2 TFT screen module:
Note: See its connections (page 15).
Front.
TFT screen.
Back.
Socket for connection with the EL632/GB2A.
9
