G 2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - CODED PANEL B
PROGRAMMING THE DOOR PANEL
Programming fields:
Continued from previous page
Field '03': Sets relay activation time.
Enables the setting of an activation time for Relay 1 and Relay 2 between 1 and 99 seconds.
Steps: Field + bell (N3301/GB2) + activation time + bell (N3301/GB2).
(Step 1)
(Step 2)
...
(Step 3)
01
(Step 4)
(Step 5)
04
Field '04': Sets relay activation mode.
Enables the setting of an activation mode for Relay 1 and Relay 2 between 0 (normally open) or 1 (normally closed).
Steps: Field + bell (N3301/GB2) + activation mode + bell (N3301/GB2).
(Step 1)
(Step 2)
(Step 3)
0
or
(Step 4)
(Step 5)
06
03
Press '03' to select field '03'.
03
Press the bell button (N3301/GB2) to confirm the selection of the field.
Define the activation time for the relays using the numeric buttons from 0 to 9. The time
99
entered must have
The factory setting is 01 seconds
Press the bell button (N3301/GB2) to finish programming the field.
Then press the number of the next field to configure or press the C button (cancel) to
C
or
exit programming mode.
04
Press '04' to select field '04'.
04
Press the bell button (N3301/GB2) to confirm the selection of the field.
Define the activation mode for the relays using the numeric buttons 0 or 1.
1
0: Normally open.
1: Normally closed.
The factory setting is 0
Press the bell button (N3301/GB2) to finish programming the field.
Then press the number of the next field to configure or press the C button (cancel) to
C
or
exit programming mode.
...
01 99
two digits .
0 1
or
