G 2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - CODED PANEL
B
DESCRIPTION OF THE KEYPAD ACCESS CONTROL MODULE
Description of the N3301/GB2 and NX3301/GB2 keypad access control module
Connection terminals:
+ -
:
Positive, negative (22 Vdc output maximum 100 mA)
IMPORTANT:
N3301/GB2 and NX3301/GB2 modules are not compatible with the connections of EL610D button
modules.
Note:
See the connections of the N3301/GB2 and NX3301/GB2 modules on page 15.
Front.
Numeric keypad.
Bell button.
Cancel button.
Back.
Socket for connection with the EL632/GB2.
Terminal strip connector for 22 Vdc output.
11
