GB2 Video Door Entry System Kit 2-wire installation Nexa Modular Code 50122084 TKIT632A VESTA2 EN REV.0117...
Page 2
NEXA MODULAR GB2 VIDEO DOOR ENTRY SYSTEM KIT - VILLAS INTRODUCTION First and foremost we would like to thank you for purchasing this product. Our commitment to satisfying our customers can be seen from our ISO-9001 certification and from the manufacturing of products like this one.
NEXA MODULAR GB2 VIDEO DOOR ENTRY SYSTEM KIT - VILLAS SAFETY PRECAUTIONS - Always disconnect the power supply before making modifications to the device. installation and handling of these devices must be carried out by authorised personnel - The wiring must run at least...
Page 4
NEXA MODULAR GB2 VIDEO DOOR ENTRY SYSTEM KIT - VILLAS DESCRIPTION OF THE EL632 GB2 SOUND MODULE Description of the EL632 GB2 sound module: Front. Color camera. LEDs (visual indications for people with impaired hearing). LEDs (activation in low light conditions).
NEXA MODULAR GB2 VIDEO DOOR ENTRY SYSTEM KIT - VILLAS DESCRIPTION OF THE NEXA MODULAR DOOR PANEL Description of the door panel: Door panel component assembly drawing: Sound module Embedding box Frame module Aluminium panel Sound module EL632 GB2 video door entry system with colour camera.
NEXA MODULAR GB2 VIDEO DOOR ENTRY SYSTEM KIT - VILLAS DOOR PANEL INSTALLATION INSTALLATION Preparing the cable entry: Break the flange to allow entry of cables through the bottom part of the embedding box. Pass the cable through the hole made in the embedding box.
NEXA MODULAR GB2 VIDEO DOOR ENTRY SYSTEM KIT - VILLAS DOOR PANEL INSTALLATION Description of the configuration jumper: Important: Do not change the factory default position of the configuration jumper. Factory default setting. Description of the door panel LED lights (for low light conditions): The door panel LED lights will turn on during a call if there is low light, allowing the person who called to be seen on the apartment's monitor.
NEXA MODULAR GB2 VIDEO DOOR ENTRY SYSTEM KIT - VILLAS DOOR PANEL INSTALLATION Adjusting the door panel communication volume: If after starting the system the door panel audio volume seems inadequate, follow these steps: - Call an apartment. - The call is received in the apartment. Establish communication by pressing the push button on the monitor.
NEXA MODULAR GB2 VIDEO DOOR ENTRY SYSTEM KIT - VILLAS DOOR PANEL INSTALLATION Configuring the contact type for Relay 1 and Relay 2 (lock release): To change the contact type for door release activation of Relay 1 and Relay 2 of the door...
DIN 46277 DIN rail latch release. IMPORTANT: the maximum number of units that can be connected to an FA-GB2/A power supply is 23 VESTA 2 GB2 monitors. Replace the protective cover once the input terminals have been wired. LOCK RELEASE INSTALLATION Lock release installation instructions: 3.5 x 25...
Configuring the end of line Lock release in the last monitor. max. 12 Vdc/270mA. Dip 6 to On. ( ) 1 Important: For AC lock releases or a second lock release, see diagram “Connection of Golmar AC and DC lock releases” on page 19.
Page 13
Dip 6 to On. ( ) 1 ( ) 1 Lock release max. 12 Vdc/270mA. ( ) 1 Important: For AC lock releases or a second lock release, see diagram “Connection of Golmar AC and DC lock releases” on page 19.
Page 14
Relay 1 Relay 2 12Vdc in the last monitor. Dip 6 to On. Lock release max. 12 Vdc/270mA. Important: For AC lock releases or a second lock release, see diagram “Connection of Golmar AC and DC lock releases” on page 19.
Page 15
12Vdc in the last monitor. Dip 6 to On. Lock release max. 12 Vdc/270mA. ( ) 2 Important: For AC lock releases or a second lock release, see diagram “Connection of Golmar AC and DC lock releases” on page 19.
Page 16
Configuring the end of line in the last monitor. Dip 6 to On. Lock release max. 12 Vdc/270mA. Important: For AC lock releases or a second lock release, see diagram “Connection of Golmar AC and DC lock releases” on page 19.
Page 17
Configurar final de línea en el último monitor. Lock release Dip 6 to On. max. 12 Vdc/270mA. ( ) 2 Important: For AC lock releases or a second lock release, see diagram “Connection of Golmar AC and DC lock releases” on page 19.
Page 18
Relay 2 Relay 1 Relay 2 12Vdc 12Vdc Lock release Lock release max. 12 Vdc/270mA. max. 12 Vdc/270mA. Important: For AC lock releases or a second lock release, see diagram “Connection of Golmar AC and DC lock releases” on page 19.
NEXA MODULAR GB2 VIDEO DOOR ENTRY SYSTEM KIT - VILLAS WIRING DIAGRAMS: Connection of Golmar AC and DC lock releases. Connection of 2 DC lock releases without “AP”: Access door panel To the FA-GB2/A power supply C1 NA1 C2 AP+ AP- P1 P2 BUSBUS...
Page 20
C/ Silici, 13 08940- Cornellá de Llobregat SPAIN Golmar se reserva el derecho a cualquier modificación sin previo aviso. Golmar se réserve le droit de toute modification sans préavis. Golmar reserves the right to make any modifications without prior notice.
