G 2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - CODED PANEL B
PROGRAMMING THE DOOR PANEL
Programming fields:
Continued from previous page
Field '13': maximum intensity level of the illumination LEDs for the camera.
Indicates the intensity level of the illumination LEDs for the camera.
(Step 1)
(Step 2)
...
(Step 3)
0
(Step 4)
(Step 5)
18
Field '18': Sets the temporary access code for Relay 1.
Enables the assignment of a temporary access code to activate Relay 1.
(Step 1)
(Step 2)
...
(Step 3)
0
(Step 4)
(Step 5)
19
Steps: Field + bell (N3301/GB2) + intensity + bell (N3301/GB2).
13
Press '13' to select field '13'.
13
Press the bell button (N3301/GB2) to confirm the selection of the field.
Define the maximum intensity level of the illumination LEDs for the camera, using the
5
numeric buttons 0 to 5, where 0 is the lowest level and 5 is the highest.
The factory setting is 4.
Press the bell button (N3301/GB2) to finish programming the field.
Then press the number of the next field to configure or press the C button (cancel) to
C
or
exit programming mode.
Steps: Field + bell (N3301/GB2) + Relay 1 access code + bell (N3301/GB2).
18
Press '18' to select field '18'.
18
Press the bell button (N3301/GB2) to confirm the selection of the field.
Define the new temporary access code for Relay 1, using the numeric buttons 0 to 9. The
9
maximum length of the access code is 12 digits.
No factory setting has been defined
Press the bell button (N3301/GB2) to finish programming the field.
Then press the number of the next field to configure or press the C button (cancel) to
C
or
exit programming mode.
...
0 5
...
0 9
23
Continued overleaf
