G 2 AUDIO AND VIDEO DOOR ENTRY SYSTEM - CODED PANEL B
PROGRAMMING THE DOOR PANEL
Managing proximity keys:
For resident proximity key access and management, the system must have an N3401/GB2 proximity access control
module. TK3401/GB2 key kit not included
IMPORTANT: It is necessary to
door panel to be managed
Adding resident keys:
Hold the MASTER CARD ADD key near to the N3401/GB2 proximity reader, communication indicator
(Step 1)
illuminate and the door panel will emit a long and then short tone to indicate that it is in 'Add resident
keys' mode.
One by one, hold all of the keys to be added to the door panel near to the N3401/GB2 proximity reader.
(Step 2)
The door panel will emit a long tone each time it stores a proximity key or two short tones if the key has
already been stored. A maximum of 320 access keys can be stored.
Once all resident proximity keys have been added, complete the process by holding the MASTER CARD
(Step 3)
ADD key near to the N3401/GB2 proximity reader. Communication indicator
panel will emit a short and then long tone to indicate that it has exited
Deleting resident keys:
Hold the MASTER CARD DELETE key near to the N3401/GB2 proximity reader, communication
(Step 1)
indicator
'Delete resident keys' mode.
One by one, hold all of the keys to be deleted from the door panel near to the N3401/GB2 proximity
(Step 2)
reader. The door panel will emit a long tone each time it deletes a proximity key or two short tones if the
key does not exist on the door panel.
Once all resident proximity keys have been deleted, complete the process by holding the MASTER CARD
(Step 3)
DELETE key near to the N3401/GB2 proximity reader. Door open indicator
panel will emit a short and then long tone to indicate that it has exited
Activating/deactivating the proximity reader:
To activate or deactivate the proximity reader, the same procedure needs to be followed; if it was initially activated it
will be deactivated and if it was initially deactivated after the process, the proximity reader will be activated.
Hold the MASTER CARD ADD key near to the N3401/GB2 proximity reader, communication indicator
(Step 1)
will illuminate and the door panel will emit a long and then short tone to indicate that it is in 'Add resident
keys' mode.
Then hold the MASTER CARD DELETE key near to the N3401/GB2 proximity reader, door open
(Step 2)
indicator
'Activate/deactivate proximity reader' mode.
Finally, hold the MASTER CARD DELETE key again to the N3401/GB2 proximity reader to
(Step 3)
activate/deactivate the proximity reader. The door panel will emit a long tone to indicate that it has been
correctly modified.
.
initially activate
before resident keys can be added/deleted
will illuminate and the door panel will emit a long and then short tone to indicate that it is in
will illuminate and the door panel will emit a long and then short tone to indicate that it is in
the MASTER CARD ADD and MASTER CARD DELETE keys on the
as indicated in the following section.
will turn off and the door
mode.
'Add resident keys'
will turn off and the door
'Delete resident keys' mode.
Continued overleaf
28
