NEXA MODULAR GB2 VIDEO DOOR ENTRY SYSTEM KIT - VILLAS
INSTALLATION OF THE DOOR PANEL
Description of the configuration jumper:
Important: Do not change the factory default position of the configuration jumper.
( )
*
Factory setting.
Description of the door panel illumination LEDs (for low light conditions):
The door panel lighting LEDs will turn on during a call if the door panel lighting
at that moment is low. This enables the user to view the person who has called
from the apartment monitor.

Description of the visual signals on the door panel:

Visual signals on the door panel for people with impaired hearing:
- While calling: LED
- During communication: LED
- During door release: LED
- End of communication: LEDs
- Calling at one door panel while another door panel is communicating (if there is more than one
door panel): LED
- While calling and the monitor is in 'Do not disturb' mode: LED
- While calling (apartment with no monitor or telephone): LED

Description of the vocal synthesis (audible signals on the door panel):

Audible signals on the door panel for people with impaired vision.
If vocal synthesis is enabled on the sound module (see page 7 and 9 for configuration), the following voice
messages can be heard on the door panel:
- While calling: 'Call is in progress'.
- During door release: 'Door Opened!'.
- End of communication: 'Communication is finished'.
- Calling at one door panel while another door panel is communicating (if there is more than one door panel):
'System is busy, try later'.
- While calling and the monitor is in 'Do not disturb' mode: 'Call is in progress'.
- While calling (apartment with no monitor or telephone): 'Resident Unavailable'.
will illuminate during in call and in communication times.
will illuminate during the communication process.
will illuminate during door release.
and will turn off.
will illuminate for 3 seconds.
will illuminate for 4 seconds.
will illuminate for 4 seconds.
