1MRS755535
8.
Feeder Protection Relay
Technical Reference Manual - ANSI Version

Check lists

Table 8.-1

Setting group 1

Variable
Pickup value of element 51P
Operate time of element 51P (51P TDLY)
Time/current characteristic for element 51P
Time multiplier 51P TD IEC
Time multiplier 51P TD ANSI
Resetting time of element 51P (51P RSET)
Pickup value of element 50P-1
Operate time of element 50P-1 (50P-1 TDLY) 1S8
Pickup value of element 50P-2
Operate time of element 50P-2 (50P-2 TDLY) 1S10
Pickup value of element 51N
Operate time of element 51N (51N TDLY)
Time/current characteristic for element 51N
Time multiplier 51N TD IEC
Time multiplier 51N TD ANSI
Resetting time of element 51N (51N RSET)
Pickup value of element 50N
Operate time of element 50N (50N TDLY)
Pickup value of element 46
Operate time of element 46 (46TDLY)
Full load current
Time constant of element 49
Alarm level of element 49
Operate time of CBFAIL (Trip Fail)
Number of AR shots
Current limit Arc50P of element ARC
Current limit Arc51N of element ARC
Checksum, SGF 1
Group/ Setting Default
Channel range setting
1 (R, W,
P)
1S1 0.30...5.0 x I 0.30 x I
n
(CT) (CT)
1S2 0.05...300 s 0.05 s
1S3 0...9 0
1S4 0.05...1.00 0.05
1S5 1.0...15.0 1.0
1S6 0.05...2.50 s 0.05 s
1S7 0.50...35.0 x 0.50 x I
I (CT) (CT)
n
0.04...300 s 0.04 s
1S9 0.50...35.0 x 0.50 x I
I (CT) (CT)
n
0.04...30.0 s 0.04 s
1S11 1.0...100% I 1.0% I
n
(CT) (CT)
1S12 0.05...300 s 0.05 s
1S13 0...9 0
1S14 0.05...1.00 0.05
1S15 1.0...15.0 1.0
1S16 0.05...2.50 s 0.05 s
1S17 5.0...800% I 5.0% I
n
(CT) (CT)
1S18 0.05...300 s 0.05 s
1S19 10...100% 100 %
1S20 1...300 s 60 s
1S21 0.30...1.50 x 0.30 x I
I (CT) (CT)
n
1S22 1...200 min 1 min
1S23 50...100% 49 95% 49
trip trip
1S24 0.10...60.0 s 0.10 s
1S25 0 = AR is not 0
in use
1 = shot 1
2 = shot 1
and 2
3 = shot 1, 2
and 3
1S26 0.50...35.0 x 2.50 x I
I (CT) (CT)
n
1S27 5.0...800% I 20% I
n
(CT) (CT)
1S61 0...255 0
REF610 REF610
Custo-
mer's
setting
n
n
n
n
n
n
n
n
167
