ABB REF610 Technical Reference Manual page 112

REF610 REF610
OBJECT
Object Variation Description
group
32 2 16-Bit Analog Change Event
without Time
32 3 32-Bit Analog Change Event with
Time
32 4 16-Bit Analog Change Event with
Time
33 0 Frozen Analog Event, all variations
33 1 32-Bit Frozen Analog Event without
Time
33 2 16-Bit Frozen Analog Event without
Time
33 3 32-Bit Frozen Analog Event with
Time
33 4 16-Bit Frozen Analog Event with
Time
40 0 Analog Output Status, all variations
40 1 32-Bit Analog Output Status
40 2 16-Bit Analog Output Status
41 0 Analog Output Block, all variations
41 1 32-Bit Analog Output Block
41 2 16-Bit Analog Output Block
50 0 Time and Date, all variations
50 1 Time and Date
(def)
50 1 Time and Date
(def)
50 2 Time and Date with Interval
51 0 Time and Date CTO, all variations
51 1 Time and Date CTO
51 2 Unsynchronized Time and Date
CTO
52 0 Time Delay, all variations
52 1 Time Delay Coarse
52 2 Time Delay Fine
60 0 All classes
60 1 Class 0 Data
60 2 Class 1 Data
60 3 Class 2 Data
60 4 Class 3 Data
70 1 File Identifier
80 1 Internal Targets
81 1 Storage Object
82 1 Device Profile
112
Feeder Protection Relay
Technical Reference Manual - ANSI Version
1
1
1
1
1
2
23
1
1
1
1
1
2
REQUEST
(slave must parse)
Function Qualifier
codes (dec) codes (hex)
06, 07, 08
06, 07, 08
06, 07, 08
06, 07, 08
06, 07, 08
06, 07, 08
7
6
06, 07, 08
06, 07, 08
06, 07, 08
06, 07, 08
00
1MRS755535
RESPONSE
(master must parse)
Function Qualifier
codes (dec) codes (hex)
129, 130 17, 28
129, 130 17, 28
129, 130 17, 28
129 17, 28
129 17, 28
129
129 7
129 28
129 17, 28
129 17, 28
129 17, 28
129 17, 28
129
