ABB REF610 Technical Reference Manual page 128

REF610 REF610
128
Feeder Protection Relay
Technical Reference Manual - ANSI Version
Status of the Channel
protection
elements
External trip 0,1
Trip lockout 0,1
CBFAIL Trip 0,1
Trip of element 0,1
ARC
Light signal 0,1
output
Open CB 0,3
command
Close CB 0,3
command
Definite trip 0,3
alarm
CB reclosing 0,3
failed
Shot due 0,3
AR Lockout 0,3
Table 5.1.17.-11 Outputs
Operation of Channel
output
contact
Output PO1 0,2
Output PO2 0,2
a)
Output PO3 0,2
Output SO1 0,2
Output SO2 0,2
Output PO3 0,2
c)
(trip lockout)
Output SO3 0,2
Output SO4 0,2
Output SO5 0,2
Enabling 0,2
activation of
output
contacts PO1,
PO2, PO3,
SO1, SO2,
SO3, SO4 and
SO5 via the
SPA bus
a)
State of output when the trip lockout function is not in use.
b)
Either O43/O103 or O46 is to be used at a time.
c)
State of output when the trip lockout function is in use.
If the optional I/O module has not been installed, a dash is shown on the LCD and "9" when the
d)
parameter is read via the SPA bus.
State of element
(R) functions (R)
O16
O17
O18
O19
O20
O21
O22
O23
O24
O25
O26
State of Recorded
output (R, W, functions (R)
P)
O41 O101
O42 O102
O43 O103
O44 O104
O45 O105
O46 -
O47 O107
O48 O108
O49 O109
O51 -
1MRS755535
Recorded Value
O76 0/1
O77 0/1
O78 0/1
O79 0/1
O80 0/1
O81 0/1
O82 0/1
O83 0/1
O84 0/1
O85 0/1
O86 0/1
Value
0/1
0/1
b)
0/1
0/1
0/1
b)
0/1
d)
0/1
d)
0/1
d)
0/1
0/1
