REF610 REF610
168
Feeder Protection Relay
Technical Reference Manual - ANSI Version
Variable
Checksum, SGF 2
Checksum, SGF 3
Checksum, SGF 4
Checksum, SGF 5
Checksum, SGB 1
Checksum, SGB 2
Checksum, SGB 3
Checksum, SGB 4
Checksum, SGB 5
Checksum, SGR 1
Checksum, SGR 2
Checksum, SGR 3
Checksum, SGR 4
Checksum, SGR 5
Checksum, SGR 6
Checksum, SGR 7
Checksum, SGR 8
Checksum, SGL 1
Checksum, SGL 2
Checksum, SGL 3
Checksum, SGL 4
Checksum, SGL 5
Checksum, SGL 6
Checksum, SGL 7
Checksum, SGL 8
Table 8.-2 Setting group 2
Variable
Pickup value of element 51P
Operate time of element 51P (51P
TDLY)
Time/current characteristic for
element 51P
Time multiplier 51P TD IEC
Time multiplier 51P TD ANSI
Resetting time of element 51P
(51P RSET)
Pickup value of element 50P-1
Operate time of element 50P-1
(50P-1 TDLY)
Group/ Setting
Channel range
1 (R, W,
P)
1S62 0...127
1S63 0...127
1S64 0...63
1S65 0...255
1S71 0...1048575
1S72 0...1048575
1S73 0...1048575
1S74 0...1048575
1S75 0...1048575
1S81 0...8388607
1S82 0...8388607
1S83 0...8388607
1S84 0...8388607
1S85 0...8388607
1S86 0...8388607
1S87 0...8388607
1S88 0...8388607
1S91 0...8388607
1S92 0...8388607
1S93 0...8388607
1S94 0...8388607
1S95 0...8388607
1S96 0...8388607
1S97 0...8388607
1S98 0...8388607
Group/ Setting range
Channel 2
(R, W, P)
2S1 0.30...5.0 x I
(CT)
2S2 0.05...300 s
2S3 0...9
2S4 0.05...1.00
2S5 1.0...15.0
2S6 0.05...2.50 s
2S7 0.50...35.0 x I
(CT)
2S8 0.04...300 s
1MRS755535
Default Custo-
setting mer's
setting
0
120
0
0
0
0
0
0
0
2108074
2108074
2108074
5461
5461
0
0
0
0
0
0
0
0
0
0
0
Default Custo-
setting mer's
setting
0.30 x I
n n
(CT)
0.05 s
0
0.05
1.0
0.05 s
0.50 x I
n n
(CT)
0.04 s
