Table 5.1.17.1.-7

Event codes E25...E42

Channel Event Description
1 E25 Pickup signal from element 49 activated
1 E26 Pickup signal from element 49 reset
1 E27 Alarm signal from element 49 activated
1 E28 Alarm signal from element 49 reset
1 E29 Trip signal from element 49 activated
1 E30 Trip signal from element 49 reset
1 E31 Trip signal from element ARC (light and
current) activated
1 E32 Trip signal from element ARC (light and
current) reset
1 E33 Trip signal from element ARC (DI and
current) activated
1 E34 Trip signal from element ARC (DI and
current) reset
1 E35 Light signal output activated
1 E36 Light signal output reset
1 E37 Trip lockout signal activated
1 E38 Trip lockout signal reset
1 E39 External trip signal activated
1 E40 External trip signal reset
1 E41 CBFAIL activated
1 E42 CBFAIL reset
Default value of event mask 1V157
Channel 2
Table 5.1.17.1.-8

Event codes E1...E16

Channel Event Description
2 E1 PO1 activated
2 E2 PO1 reset
2 E3 PO2 activated
2 E4 PO2 reset
2 E5 PO3 activated
2 E6 PO3 reset
2 E7 SO1 activated
2 E8 SO1 reset
2 E9 SO2 activated
2 E10 SO2 reset
2 E11 SO3 activated
2 E12 SO3 reset
2 E13 SO4 activated
2 E14 SO4 reset
1MRS755535
Weighting Default
factor value
1 0
2 0
4 1
8 0
16 1
32 0
64 1
128 0
256 0
512 0
1024 0
2048 0
4096 1
8192 0
16384 0
32768 0
65536 0
131072 0
4180
Weighting Default
factor value
1 1
2 1
4 0
8 0
16 0
32 0
64 0
128 0
256 0
512 0
1024 0
2048 0
4096 0
8192 0
