Table 5.1.15.1.-7

Mapping of Modbus data: analog data

Description
Phase current I x I (CT)
a n
Phase current I x I (CT)
b n
Phase current I x I (CT)
c n
Ground-fault current x I (CT)
n
Phase unbalance
Table 5.1.15.1.-8

Mapping of Modbus data: digital data

Description
Pickup signal from element 51P
Pickup signal from element 51P CD
Trip signal from element 51P
Trip signal from element 51P CD
Pickup signal from element 50P-1
Pickup signal from element 50P-1 CD
Trip signal from element 50P-1
Trip signal from element 50P-1 CD
Pickup signal from element 50P-2
Pickup signal from element 50P-2 CD
Trip signal from element 50P-2
Trip signal from element 50P-2 CD
Pickup signal from element 51N
Pickup signal from element 51N CD
Trip signal from element 51N
Trip signal from element 51N CD
Pickup signal from element 50N
Pickup signal from element 50N CD
Trip signal from element 50N
Trip signal from element 50N CD
Pickup signal from element 46
Pickup signal from element 46 CD
Trip signal from element 46
Trip signal from element 46 CD
Pickup signal from element 49
Pickup signal from element 49 CD
Alarm signal from element 49
Alarm signal from element 49 CD
Trip signal from element 49
Trip signal from element 49 CD
Trip signal from element ARC (light and
current)
96
Feeder Protection Relay
Technical Reference Manual - ANSI Version
HR/IR address
(.bit)
404
405
406
407
408
HR/IR address (.bit)
409.00
409.01
409.02
409.03
409.04
409.05
409.06
409.07
409.08
409.09
409.10
409.11
409.12
409.13
409.14
409.15
410.00
410.01
410.02
410.03
410.04
410.05
410.06
410.07
410.08
410.09
410.10
410.11
410.12
410.13
410.14
DI/Coil bit Writeable
address
DI/Coil bit Writeable
address
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
1MRS755535
Value range Comment
0...5000 0...50 x FLA
0...5000 0...50 x FLA
0...5000 0...50 x FLA
0...20000 0...2000% I
n
(CT)
0...100 0...100%
Value Comment
range
0/1 1 = activated
0/1 1 = activated
0/1 1 = activated
0/1 1 = activated
0/1 1 = activated
0/1 1 = activated
0/1 1 = activated
0/1 1 = activated
0/1 1 = activated
0/1 1 = activated
0/1 1 = activated
0/1 1 = activated
0/1 1 = activated
0/1 1 = activated
0/1 1 = activated
0/1 1 = activated
