ABB REF610 Technical Reference Manual page 110

REF610 REF610
OBJECT
Object Variation Description
group
20 2 16-Bit Binary Counter
20 3 32-Bit Delta Counter
20 4 16-Bit Delta Counter
20 5 32-Bit Binary Counter without Flag
20 6 16-Bit Binary Counter without Flag
20 7 32-Bit Delta Counter without Flag
20 8 16-Bit Delta Counter without Flag
21 0 Frozen Counter, all variations
21 1 32-Bit Frozen Counter
21 2 16-Bit Frozen Counter
21 3 32-Bit Frozen Delta Counter
21 4 16-Bit Frozen Delta Counter
21 5 32-Bit Frozen Counter with Time of
Freeze
21 6 16-Bit Frozen Counter with Time of
Freeze
21 7 32-Bit Frozen Delta Counter with
Time of Freeze
21 8 16-Bit Frozen Delta Counter with
Time of Freeze
21 9 32-Bit Frozen Counter without Flag
21 10 16-Bit Frozen Counter without Flag
21 11 32-Bit Frozen Delta Counter
without Flag
21 12 16-Bit Frozen Delta Counter
without Flag
22 0 Counter Change Event, all
variations
22 1 32-Bit Counter Change Event
without Time
22 2 16-Bit Counter Change Event
without Time
22 3 32-Bit Delta Counter Change Event
without Time
22 4 16-Bit Delta Counter Change Event
without Time
22 5 32-Bit Counter Change Event with
Time
22 6 16-Bit Counter Change Event with
Time
110
Feeder Protection Relay
Technical Reference Manual - ANSI Version
1, 7, 8, 20, 21,
22
1
1
1
1
1
1
1
1
1
1
REQUEST
(slave must parse)
Function Qualifier
codes (dec) codes (hex)
00, 01, 06, 07,
08, 17, 28
00, 01, 06, 07,
08, 17, 28
00, 01, 06, 07,
08, 17, 28
00, 01, 06, 07,
08, 17, 28
00, 01, 06, 07,
08, 17, 28
00, 01, 06, 07,
08, 17, 28
06, 07, 08
06, 07, 08
06, 07, 08
06, 07, 08
06, 07, 08
1MRS755535
RESPONSE
(master must parse)
Function Qualifier
codes (dec) codes (hex)
129 00, 01, 17, 28
129 00, 01, 17, 28
129 00, 01, 17, 28
129 00, 01, 17, 28
129 00, 01, 17, 28
129 00, 01, 17, 28
129, 130 17, 28
129, 130 17, 28
129, 130 17, 28
129, 130 17, 28
129, 130 17, 28
