CyberData 011233 Operation Manual page 45

Web Page Item
Codec
RTP Settings
RTP Port (even)
Jitter Buffer
Note
Note
1. Enter the IP address of the SIP Server.
2. Enter the port numbers used for SIP signaling:
3. Enter the SIP registration parameters:
4. For SIP Registration, designate whether you want the VoIP Paging Server to register with your
5. At Unregister on Reboot:
6. In the Register Expiration field, enter the number of seconds the SIP Paging Adapter
CyberData Corporation
Table 2-11. SIP Configuration Parameters (continued)
Description
Select desired codec (only one may be chosen).
Specify the port number used for the RTP stream after establishing a SIP
call. This port number must be an even number and defaults to 10500.
The supported range is 0-65536. Enter up to 5 digits.
Specify the size of the jitter buffer (in milliseconds) used for SIP calls. Valid
values are 50 -1000.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
Click on the Toggle Help button to see a short description of some of the
web page items. First click on the Toggle Help button, and you will see a
question mark (
mouse pointer to hover over a question mark to see a short description of
a specific web page item.
You must click on the Save button and then the Reboot button for the changes to take
effect.
For specific server configurations, go to the following website address:
http://www.cyberdata.net/connecting-to-compatible-ip-pbx-servers/
a. Remote SIP Port
b. Local SIP Port
a. SIP User ID
b. Authenticate ID
c. Authenticate Password
SIP server.
a. Select Yes to automatically unregister the SIP Paging Adapter when you reboot it.
b. Select No to keep the SIP Paging Adapter registered when you reboot it.
registration lease remains valid with the SIP Server. The SIP Paging Adapter automatically re-
registers with the SIP server before the lease expiration timeout.
) appear next to some of the web page items. Move the
931087G
Setting Up the SIP Paging Adapter
Configure the SIP Parameters
Operations Guide
37
