CyberData SIP Paging Adapter Connections

Peavey mma 8150t amplifier

Hide thumbs Also See for SIP Paging Adapter:

Peavey MMA 8150T Amplifier to SIP Paging Adapter Connections

The IP Endpoint Company

Peavey MMA 8150T Amplifier

SIP Paging Adapter Connections

+ -

PGM IN

CyberData SIP Paging Adapter's RCA line level output can connect to either an AUX 2 module

or a TPM-S2 Module.

This page shows the possible connections to an AUX 2 module.

Connect the SIP Paging Adapter's Line Out to one of the RCA phono input jacks.

930715A

Table of Contents

Do you have a question about the SIP Paging Adapter and is the answer not in the manual?

Page 1 SIP Paging Adapter Connections PGM IN Notes CyberData SIP Paging Adapter's RCA line level output can connect to either an AUX 2 module or a TPM-S2 Module. This page shows the possible connections to an AUX 2 module. Connect the SIP Paging Adapter's Line Out to one of the RCA phono input jacks.
Page 2 This page shows possible connections to a TPM-S2 module Relay Contact - Normally Open Connect the SIP Paging Adapter's Page Port output terminal pins to the INPUT a.The 600-Ohm audio output of the page port is on the TPM-S2 module.
