Web Page Item
SIP Server
Remote SIP Port
Local SIP Port
Outbound Proxy
Outbound Proxy Port
User ID
Authenticate ID
Authenticate Password
Re-registration Interval (in seconds)
Relay rings to multicast
Multicast Address
Multicast Port
Call Disconnection
Terminate Call After Delay
Codec Selection
Force Selected Codec
CyberData Corporation
Table 2-11. SIP Configuration Parameters (continued)
Description
Enter the SIP server address as an IPv4 address in dotted decimal
notation or a fully qualified domain name. This parameter also becomes
the host portion of the SIP-URI for the device's Nightringer extension on
the SIP server. This field can accept entries of up to 255 characters in
length.
The Remote SIP Port is the port number the device will use as the
destination port when sending SIP messages for the Nightringer
extension. The default Remote SIP Port is 5060. The supported range is
0-65536. Enter up to 5 digits.
The Local SIP Port is the port number the device will use to receive SIP
messages for the Nightringer extension. This value cannot be the same as
the
Local SIP Port
5061. The supported range is 0-65536. Enter up to 5 digits.
Enter the Outbound Proxy address as an IPv4 address in dotted decimal
notation or a fully qualified domain name (FQDN). When an IP address is
configured, the device will send all SIP messages to this IP address for the
Nightringer extension. When an FQDN is configured, the device will run
DNS NAPTR, SRV, and A queries on the FQDN to resolve an IP address
to which it will send all SIP messages for the Nightringer extension. This
field can accept entries of up to 255 characters in length.
The Outbound Proxy Port is port number used as the destination port
when sending SIP messages to the outbound proxy for the Nightringer
extension. A value of 0 will default to 5060. The supported range is 0-
65536. Enter up to 5 digits.
Specify the SIP User ID for the SIP server. This parameter becomes the
user portion of the SIP-URI for the device's Nightringer extension. Enter
up to 64 alphanumeric characters.
Specify the Authenticate ID for the SIP Server. This parameter is required
for SIP registration authentication. Enter up to 64 alphanumeric
characters.
Specify the Authenticate Password for the SIP Server. This parameter is
required for SIP registration authentication. Enter up to 64 alphanumeric
characters.
The SIP Re-registration Interval (in seconds) is the SIP Registration lease
time, also known as the expiry. The supported range is 30-3600 seconds.
Enter up to 4 digits.
When selected, the device will play ring tones to the specified multicast
address and port.
The multicast address used for nightring audio.
The multicast port used for nightring audio.
Automatically terminate an active call after a given delay in seconds. A
value of 0 will disable this function. Enter up to 8 digits.
When configured, this option will allow you to force the device to negotiate
for the selected codec [PCMU(G.711, u-law), PCMA(G.711, a-law), or
G.722]. Otherwise, the device will perform codec negotiation using the
default list of supported codecs.
931087G
for the primary extension. The default Local SIP Port is
Setting Up the SIP Paging Adapter
Configure the SIP Parameters
Operations Guide
36
