CyberData 011280 Quick Start Manual

Singlewire Paging Adapter
The IP Endpoint Company
Quick Start Guide

1.0 Out-of-Box and Prior to Final Installation

1.1. Verify that you have received all of the parts listed on the Installation Quick Reference placemat.
1.2. Download the current manual, otherwise known as an Operation Guide, which is available on the
Documentation page at the following website address:
http://www.cyberdata.net/products/voip/digitalanalog/singlewirepagingadapter/docs.html

2.0 Select Power Source

PoE Switch
Set PoE power type to IEEE 802.3af
Power Class 0 (15.4W)

3.0 Power Test

3.1. Plug in the CyberData device and monitor the LED activity on the front of the device. See the following figure:
3.2. The GREEN/BLUE Status LED and the
the initial network setup.
The round, GREEN/BLUE
the device has been initialized, this LED blinks at one second intervals.
The square, GREEN/AMBER
established. The Link LED changes color to confirm the auto-negotiated connection speed:
• The Link LED is
• The Link LED is
The GREEN Paging LED comes on while the device is booting and turns off after 15 seconds. This light blinks
when a page is in progress. You can disable Beep on Initialization on the Device Configuration page.
The square, GREEN
Quick Start Guide
CAT6 cable recommended—for longer distances
Make sure port is not in trunk mode
Set port to full duplex/ 100mbps
GREEN
Status LED on the front of the device comes on indicating that the power is on. Once
Link LED above the Ethernet port indicates that the network connection has been
GREEN at 10 Mbps.
AMBER at 100 Mbps.
Activity LED blinks when there is network traffic.
PoE Injector
Be sure you are using a non-PoE switch or port
Link
(GREEN/AMBER
Activity
(GREEN LED)
Status
(GREEN/BLUE
Paging
(GREEN LED)
Paging LED both blink at a rate of 10 times per second during
LED)
LED)
931120A
