CyberData 11233 Installation Quick Reference

Mounting
You have the option to use the following mounting template to mark, and then drill two 3/16-inch (0.1875-inch) holes for
the mounting anchors.
To install and mount the SIP Paging Adapter:
1. Install the mounting anchors in the holes, and position the SIP Paging Adapter mounting holes over the anchors.
2. Use the two #6 sheet metal screws to secure the SIP Paging Adapter onto the mounting surface.
Drill Hole Size for Anchor Installation: 3/16-inch (0.1875-inch)
Dimensions
4.1 [104.0]
© 2013, CyberData Corporation, ALL RIGHTS RESERVED
6.0 [152.4]
Dimensions are in Inches [Millimeters]
Dimensions are in Inches [Millimeter]
930613B Quick Reference
The IP Endpoint Company
The SIP Paging Adapter enables access to existing analog paging systems through a VoIP phone system. This interface
supports standard amplifier connections and supports paging to multiple zones from a VoIP phone.
Parameter
IP Addressing
a
IP Address
Web Access Username
Web Access Password
a
Subnet Mask
a
Default Gateway
a. Default if there is not a DHCP server present.
Getting Started
• Be sure that you have received all the parts described in the
• Download the Operations Guide at the following website:
http://www.cyberdata.net/products/voip/legacyanalog/sippagingadapter/docs.html
Parts List
(1) SIP Paging Adapter
Contacting CyberData
Corporate Headquarters
CyberData Corporation
1.2 [29.6]
3 Justin Court
Monterey, CA 93940, USA
Phone: 831-373-2601
Fax: 831-373-4193
www.CyberData.net
Quick Reference
Installation Quick Reference
SIP Paging Adapter
SIP Compliant
011233
Factory Default
Setting
DHCP
10.10.10.10
admin
admin
255.0.0.0
10.0.0.1
Parts List section.
(1) Mounting Template
(see the last page)
Sales: (831) 373-2601 ext. 334
Support: 831-373-2601 ext. 333
Web: http://www.cyberdata.net/support/contactsupportvoip.html
RMA Dept: (831) 373-2601 ext. 136
Email: RMA@CyberData.net
RMA Status: http://www.cyberdata.net/support/rmastatus.html
Warranty and RMA information is available at the following website:
http://www.cyberdata.net/support/warranty/index.html
930613B © 2013, CyberData Corporation, ALL RIGHTS RESERVED
(1) Mounting Kit
(2) #6 x1.25-inch, PanHead,
Phillips Sheet Metal Screw
(2) Plastic Anchors
