Polycom SpectraLink 1725-36028-001 Administration Manual page 83

Action Entry Description
(blank) No action is assigned to softkey.
F Used with 0-9, #, *.
Sends a message to the PBX to activate
the feature programmed to this sequence.
L Used with 0-9, #, *.
Sends a message to the PBX to activate
the feature associated with this sequence.
MUTE Mutes handset
ADMIN Initiates Admin sequence
OAI Used with 0-9, #, *.
Initiates assigned application
FLASH Initiates hookflash
The FLASH action may have keys
following for feature activation
HOLD Places active call on hold
SPKR Activates the speakerphone in the
SpectraLink 8020/8030 handsets
PN: 1725-36028-001_T.doc
Speakerphone softkey programming
(SpectraLink 8020/8030 only)
The SpectraLink 8020/8030 Wireless Telephones have an internal
speakerphone which is activated through a softkey. Polycom
recommends programming Level 0, softkey A for the speakerphone
as that position matches the standby position the handset
automatically assigns to the speakerphone.
The speakerphone softkey will be blank on the e340/h340/i640
handsets. If the speakerphone is disabled in the Admin menu, the
Spkr softkey will not appear during standby. However, if it has been
programmed in the SpectraLink 8000 Telephony Gateway, the
softkey will appear during active mode but it will be non-functional.
Level Softkey
0 A
Softkey and Shortcut Key Programming
Shortcut Menu Label
Speakerphone
Example
Label: Mail
Action: F2
Activates message retrieval.
Label: ReleaseLine
Action: L0
Releases the current line appearance.
Label: Mute
Action: MUTE
Activates Mute function in handset.
Label: Admin
Action: ADMIN
Activates an administrative function in the PBX.
Label: Phone Book
Action: OAI7
Activates application that opens the OAI
application assigned to F7 in the OAI
configuration.
Label: Redial
Action: FLASH##4
Activates the redial feature.
Label: HOLD
Action: HOLD
Hold message to PBX.
Label: Spkr
Action: SPKR
Activates the speakerphone
Spkr
Softkey
Action
Label
Spkr SPKR
83
