SpectraLink 8000 Telephony Gateway Administration Guide
20
wall. Four #8 x 3/4" panhead wood screws (or similar device) are
required for each component.
10BaseT Cables: RJ-45 connector at each SpectraLink 8000
•
Telephony Gateway. Connection to Ethernet switch.
CAT 5 Cable: RJ-45 connector at the SpectraLink 8000 SVP
•
Server. Connection to Ethernet switch.
Modem Cable: DB-9 female, null-modem cable. Required for
•
initial setup of the SpectraLink 8000 Telephony Gateway and SVP
Server.
Outlet Strip: For installations with more than one SpectraLink
•
8000 Telephony Gateway, use an outlet strip with a built in power
switch to allow SpectraLink 8000 Telephony Gateways to be
turned on and off together.
• Grounding materials per section below Grounding Instructions.
PN: 1725-36028-001_T.doc
