- Page 1 Inter-Tel Axxess and Axxent LinkPlus Interface Guide SpectraLink 6000 System SpectraLink 8000 System January 2008 Edition 1725-36135-001 Version D...
- Page 2 Polycom personnel and customers. The LinkPlus drawings and specifications contained herein Link are the property of Polycom and shall be neither NetLink reproduced in whole or in part without the prior written approval of Polycom, nor be implied to...
-
Page 3: About This Guide
(handsets) emulate digital telephone sets to deliver advanced capabilities such as multiple line appearances and LCD display features. This document explains the programming or administration required to use the host digital switch with the following Polycom products: SpectraLink 6000 System – SpectraLink 6300 MCU The SpectraLink 6300 MCU supports up to 3,200 Handsets and up to 1,000 Base Stations. -
Page 4: Related Documents
Available at http://www.spectralink.com/resources/interface_guides.jsp. Contacting Polycom Polycom wants you to have a successful installation. If you have questions please contact our Customer Support Hotline at (800) 775-5330. The hotline is open Monday through Friday, 6 a.m. to 6 p.m. Mountain time. -
Page 5: Icons And Conventions
About this Guide Icons and Conventions This manual uses the following icons and conventions. Caution! Follow these instructions carefully to avoid danger. Note these instructions carefully. Label This typeface indicates a key, label, or button on SpectraLink hardware. PN: 1725-36135-001_D.doc... -
Page 7: Plan Programming
Plan the Interface The system administrator programs the telephone system for use with the Wireless Telephone System using the normal administration terminal or procedures. Programming can be done after the handsets are registered. Recommended programming includes assigning extension numbers to the handsets and programming features on the telephone system so they are easily accessible from the handsets. - Page 8 LinkPlus Interface Guide: Inter-Tel Axxess and Axxent “model” handsets then use the model as a template to program the other handsets. • All handsets are different: All handsets are programmed differently, so each handset will be programmed individually. Before installation, the parameters of the wired phones should be verified to plan the parameters required for the handsets.
- Page 9 Plan the Interface Assign Extension Numbers The wire contractor should inform the system administrator which port numbers have been designated for the handsets. The system administrator may use the Extension Assignments Worksheet at the end of this document to track the port numbers, extensions, users, and features assigned to handsets.
- Page 10 LinkPlus Interface Guide: Inter-Tel Axxess and Axxent Feature Programming Requirements When planning the interface, the following information must be taken into account: Line sequences The handset uses two types of key sequences to access PBX features and multiple lines. Line sequences are those where the user presses key and then a number key.
- Page 11 SpectraLink 6100 MCU For the SpectraLink 6100 MCU, the handset function menu text can only be changed via remote configuration through the services of Polycom’s Customer Support. SpectraLink 8000 Telephony Gateways Function menu text options can be changed in the Administration Console of the SpectraLink 8000 Telephony Gateways.
- Page 12 LinkPlus Interface Guide: Inter-Tel Axxess and Axxent Ring types Handset ring types (soft, normal, vibrate, etc.) are programmed by the handset user and are not accessible or changeable by the system switch. Whenever possible the audible ringer on the handset will follow the cadence provided by the system switch.
- Page 13 A trained Inter-Tel technician or system administrator will be on site with the SpectraLink installer to program the system. • The SpectraLink 6000 System or SpectraLink 8000 Telephony Gateway is installed and the handsets are available for programming. The Inter-Tel Axxess digital interface to the SpectraLink 6000 System is licensed for use in the U.S.
- Page 14 LinkPlus Interface Guide: Inter-Tel Axxess and Axxent SpectraLink 8000 Telephony Gateways Connect to the SpectraLink 8000 Telephony Gateway using the serial or modem interface. From the Main Menu, choose Gateway Configuration. Scroll to Telephone Switch Type and press enter to change this field, from the Submenu of PBX types, select Inter-Tel Axxess or Axxent.
- Page 15 Interface Implementation The FCN [number] and LINE [number] labels represent the key sequence on the handset mapped to the corresponding key on the desk set. The handset function menu default settings are shown in the table below; these may be changed as described above in Function Menu Programming.
- Page 16 LinkPlus Interface Guide: Inter-Tel Axxess and Axxent Program Axxess or Axxent Program the Inter-Tel system for use with the Wireless Telephone System using the Axxess PAL software package that is loaded on your programming PC. Copy settings from a wired set If possible, copy the settings from an existing wired telephone with similar features and keys to create a “template”...
-
Page 17: Extension Assignments Worksheet
Extension Assignments Worksheet Shelf: _______ Interface Module: _______ Interface Handset Handset # Ext. # Name Module Comment Serial # Circuit # Handset 1 Handset 2 Handset 3 Handset 4 Handset 5 Handset 6 Handset 7 Handset 8 Handset 9 Handset 10 Handset 11 Handset 12 Handset 13...
