Navigating through the Administration
Console Screens
To Perform this Function:
Select function from menu
Display menu associated with
highlighted field
Exit Screen
Move one line up
Move one line down
Move one field to the left
Move one field to the right
Scroll
PN: 1725-36028-001_T.doc
SpectraLink 8000 Telephony Gateway Administration Overview
Use the following keys to move around the Administration Console
screens.
Press:
Use arrow keys to highlight selection, press Enter
Enter: the Enter key will either display the options associated with an
item or allow you to type an entry into the field.
Esc: the Esc key will take you to the previous screen.
Corresponding arrow key
If a screen has more lines of information than can be displayed at
once, the scroll feature uses the arrow keys and wraps. Pressing the
down arrow key at the last line will move the cursor to the top line.
Pressing the up arrow key at the top line will move the cursor to the
last line.
The top line of each administration screen displays the hostname and
IP address of the current SpectraLink 8000 Telephony Gateway
connection.
