CSAT-5060 50 Watt C-Band Transceiver
Remote Control
Arguments
for
Command Command
(Instruction or
Parameter Code and Response
Type qualifier) to Query
CSAT Global CGC= 60 bytes,
Configuration with
numerical
entries
fixed value
entries, and
delimiters
Redundancy RAM= 1 byte,
Controller value of 0,1
Box
Auto/Manual
Mode
Redundancy RTG= None
Controller
Box Toggle
Description of Arguments
Note that all arguments are ASCII
numeric codes between 48 and 57.
Command or Query. Global configuration of Unit, in the
form: FFFF.FAA.AAMSB.BGG.GGZffff.faa.aamsb.b
gg.ggNRCXOOOLWWDeeeeeee, where:
F = Tx Frequency – same as UFQ= (6 bytes)
A = Tx Attenuation – same as UAT= (5 bytes)
M = Tx Mute – same ad UMU= (1byte)
S = Tx Slope Mode – same as USM= (1 byte)
B = Tx Slope Value – same as USA= (3 bytes)
G = Tx Gain Offset – same as UGO= (5 bytes)
Z = Tx Amplifier State – same as AMP= (1 byte)
f = Rx Frequency – same as UFQ= (6 bytes)
a = Rx Attenuation – same as UAT= (5 bytes)
m = Rx Mute – same ad UMU= (1byte)
s = Rx Slope Mode – same as USM= (1 byte)
b = Rx Slope Value – same as USA= (3 bytes)
g = Rx Gain Offset – same as UGO= (5 bytes)
N = Mute Mode – same as MUT= (1 byte)
R = Auto Fault Recovery – same as AFR= (1 byte)
C = Cold Start Mode – same as CLD= (1 byte)
X = Ext Ref Fault Logic – same as XRF= (1 byte)
O = Ref Oscillator Adjust – same as REF= (3 bytes)
L = LNA Current Source – same as LCS= (1 byte)
W = LNA Current Window – same as LCW= (3 bytes)
D = LNA Fualt Logic – same as LFL= (1 byte)
e = expansion (7 bytes), set to '0'
Example: CGC=5901.012.75000.3-0.0013652.5
12.75000.3-0.00110108719900000000
Command or Query.
RAM controls whether or not the Redundancy Controller
is in automatic or manual mode, where:
0 = Manual Mode,
1 = Auto Mode.
Example: RAM=1
Command only.
RTG= sent to the online CSAT will cause the
Redundancy Box to toggle the Tx and Rx switches.
Example: RTG=
Response to
Command
(Slave to Master)
CGC= (message ok)
CGC? (received ok,
But invalid
arguments found)
RAM= (message ok)
RAM? (received ok,
But invalid
arguments found)
RTG= (message ok)
RTG? (received ok,
But invalid
arguments found)
A-10
MN/CSAT506050.IOM
Query
(Instruction
code and Response to query
qualifier) (Slave to Master)
CGC? CGC= FFFF.FAA.AAMS
B.BGG.GGZffff.faa.aams
b.bgg.ggNRCXOOOLWWDeeeeee
e
(same format as command
arguments)
RAM? RAM=x
(same format as command
arguments)
N/A N/A
