Comtech EF Data CSAT-5060 Installation And Operation Manual page 85

CSAT-5060 50 Watt C-Band Transceiver
Remote Control
Arguments
for
Command Command
(Instruction or
Parameter Code and Response
Type qualifier) to Query
Retrieve N/A 113 bytes,
Configuration alpha
Status numerical
Retrieve LNA N/A 23 bytes,
Status alpha
numerical
Retrieve N/A 32 bytes,
Utility Status alpha
numerical
Retrieve N/A 37 bytes,
Redundancy alpha
Status numerical
Description of Arguments
Note that all arguments are ASCII
numeric codes between 48 and 57.
Query only.
Used to Query the configuration status of the CSAT
Example: RCS='cr'
UFQ=5845.0'cr'
DFQ=3625.0'cr'
UAT=12.50'cr'
DAT=01.50'cr'
ONL=YES'cr'
XMT=ON'cr'
AMP=ON'cr'
UMU=OFF'cr'
RCV=ON'cr'
DMU=OFF'cr'
CLD=OFF'cr'
AFR=ON'cr'
EXT=NO 'cr''lf'
Query only.
Used to Query the LNA status of the CSAT
Example: RLS='cr'
LCS=ON'cr'
LCW=40'cr'
LFL=1'cr''lf'
Query only.
Used to Query the utility status of the CSAT
Example: RUS='cr'
BDR=9600'cr'
REF=087'cr'
USA=0.3'cr'
DSA=0.4'cr''lf'
Query only.
Used to Query the utility status of the CSAT
Example: RRS='cr'
R 5V=5.0'cr'
R 12V=11.8'cr'
TX SW=OK'cr'
RX SW=OK'cr''lf'
Response to
Command
(Slave to Master)
N/A
N/A
N/A
N/A
A-13
MN/CSAT506050.IOM
Query
(Instruction
code and Response to query
qualifier) (Slave to Master)
RCS? RCS=x....x (see description for
details of arguments)
RLS? RLS=x....x (see description for
details of arguments)
RUS? RUS=x....x (see description for
details of arguments)
RRS? RRS=x....x (see description for
details of arguments)
Revision 0
