CSAT-5060 50 Watt C-Band Transceiver
Remote Control
Arguments
for
Command Command
(Instruction or
Parameter Code and Response
Type qualifier) to Query
List New N/A 145 bytes
Alarms
(Retrieve
next 5
unread
Stored
Alarms)
Total New N/A 2 bytes,
Alarms numerical
(Retrieve
Number of
unread
Stored
Alarms)
Retrieve N/A 6 bytes,
Serial alpha
Number numerical
C00000 to
C99999
Retrieve N/A 20 bytes,
Equipment alpha
Type numerical
Circuit CID= 24 bytes,
Identification alpha
Message numerical
Description of Arguments
Note that all arguments are ASCII
numeric codes between 48 and 57.
Query only
CSAT returns the oldest 5 Stored Events that have not
yet been read over the remote control. Reply format:
Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-
body{CR}Sub-body, where Sub-body=
YYYYYYYYYY ZZ mmddyy hhmmss,
YYYYYYYYYY being the fault description.
ZZ being the alarm typr.
FT = Fault
OK = Clear
IF = Information
If there are no new events, the CSAT will reply with
LNA*. Note: the CSAT incorporates a circular buffer
capable of holding 100 events/alarms.
Query only.
CSAT returns the number of Stored Events which
remain unread, in the form xx. Note: This means unread
over the remote control – viewing the stored events
from the front panel of the modem does not affect this
value.
Example reply: TNA=18'cr''lf'
Query only.
Used to Query the units 6 digit serial number.
Slave returns its S/N, in the form xxxxxx.
Example: RSN=C00165'cr''lf'
Query only.
CSAT returns a string indicated the Model Number and
the value of internal software revision installed
Example: RET=CSAT-5060/050 V1.02'cr''lf'
Command or Query.
Sets or queries the user-defined Circuit ID string, which
is a fixed length of 24 characters.
Valid characters include:
Space ( ) * + _ , . / 0-9 A-Z
Response to
Command
(Slave to Master)
N/A
N/A
N/A
N/A
CID= (message ok)
CID? (received ok,
but invalid
arguments found)
A-12
MN/CSAT506050.IOM
Query
(Instruction
code and Response to query
qualifier) (Slave to Master)
LNA? LNA=YY..ss
(see description for details of
arguments)
TNA? TNA=xx (see description for details
of arguments)
RSN? RSN=xxxxxx (see description for
details of arguments)
RET? RET=x....x (see description for
details of arguments)
CID? CID=x....x (see description for
details of arguments)
