Table 2-3. CSAT Mounting Brackets, AS/0415

Part No.
FP/BR0067
HW/M8FLATSS
HW/M8LOCKSS
HW/M8SPRINGNUT
HW/M8X1.25MMHEXSS
HW/M8X1.25X25HEXSS
Nomenclature
Bracket, Pole Mount Kit
Washer, Flat, M8 SS, Metric
Washer, Splitlock, M8, SS, Metric
Springnut, M8 xX 1.25
Bolt, Hex M8X1.25X16MM, SS
Bolt, Hexhead, M8X1.25X25, SS
2–5
Revision 0
MN/CSAT506050.IOM
QTY
2
8
8
4
4
4
Figure 2-2.
CSAT Mounting Brackets,
AS/0415
