Comtech EF Data CSAT-5060 Installation And Operation Manual page 81

CSAT-5060 50 Watt C-Band Transceiver
Remote Control
Arguments
for
Command Command
(Instruction or
Parameter Code and Response
Type qualifier) to Query
Online N/A 1 byte,
Status value of 0,1
LNA Current LCS= 1 byte,
Source value of 0,1
LNA Fault LFL= 1 byte,
Logic value of 0,1
Calibrate CAL= None
LNA Current
LNA Current LCW= 2 bytes,
Window numerical
External XRF= 1 byte,
Reference value of 0,1
Fault Logic
Description of Arguments
Note that all arguments are ASCII
numeric codes between 48 and 57.
Query Only.
Online status, where:
0 = OFFLINE,
1 = ONLINE
Example: ONL=1
Command or Query.
LNA Current Source, where:
0 = Disabled,
1 = Enabled
Example: LCS=1
Command or Query.
LFL controls whether or not the Summary Fault Relay
(SFR)
is affected by the LNA Current window monitor, where:
0 = A LNA Current fault does not effect the SFR,
1 = A LNA Current fault will effect the SFR.
Example: LFL=1
Command only.
This command is used to set the calibration point for
the LNA current alarm feature.
Example: CAL=
Command or Query.
LNA Current Monitor Window, this command allows the
user to set the alarm window in ± % of the calibrated
LNA current. Valid inputs are 20 to 50 in increments of
5. In addition, setting the value to 99 disables the alarm
function.
Example: LCW=30, set the alarm window at ± 30%.
Command or Query.
XRF controls whether or not the Software monitors the
external refernece source. If enabled and no source is
present a fault will be reported.
0 = A Ext Reference not monitored
1 = A Ext Reference is monitored and the lock state
reported.
Example: XRF=1
Response to
Command
(Slave to Master)
ONL= (message ok)
ONL? (received ok,
but invalid
arguments found)
LCS= (message ok)
LCS? (received ok,
but invalid
arguments found)
LFL= (message ok)
LFL? (received ok,
But invalid
arguments found)
CAL= (message ok)
LCW= (message ok)
LCW? (received ok,
but invalid
arguments found)
XRF= (message ok)
XRF? (received ok,
But invalid
arguments found)
A-9
MN/CSAT506050.IOM
Query
(Instruction
code and Response to query
qualifier) (Slave to Master)
ONL? ONL=x
(same format as command
arguments)
LCS? LCS=x
(same format as command
arguments)
LFL? LFL=x
(same format as command
arguments)
N/A N/A
LCW? LCW=xx
(same format as command
arguments)
XRF? XRF=x
(same format as command
arguments)
Revision 0
